Overview of All Actions
Event Instruction
R1 ON
R1 OFF
R1 NC
R1 SC
R1 RC
R1 CALLC
R1 ONC
R1 OFFC
Address D: Format: DBi.DBXm.n (i = block number, m = byte address, n = bit address)
For CALL[C] FB/SFB, an instance DB is required.
13-12
Action
Address Location
Area
S i
S i
Q,I,M,D* m.n
Q,I,M,D* m.n
Q,I,M,D* m.n
FB, FC, Block
SFB, SFC number
S i
S i
S7-GRAPH for S7 300/400 Programming Sequential Control Systems
Explanation
As soon as a registration is
set, step i is activated.
As soon as a registration is
set, step i is deactivated.
As soon as a registration is
set and the condition
(interlock) is satisfied, the
signal state of the address is
1.
As soon as a registration is
set and the condition
(interlock) is satisfied, the
address is set to 1 and then
remains set to 1.
As soon as a registration is
set and the condition
(interlock) is satisfied, the
address is set to 0 and then
remains set to 0.
As soon as a registration is
set and the condition
(interlock) is satisfied, the
specified block is called.
As soon as a registration is
set and the condition
(interlock) is satisfied, step i is
activated.
As soon as a registration is
set and the condition
(interlock) is satisfied, step i is
deactivated.
C79000-G7076-C526-01
Address
range
i = step
number
i = step
number
0.0 to
65535.7
0.0 to
65535.7
0.0 to
65535.7
i = step
number
i = step
number
