- Page 1 Automatic Industrial Cordless Brushless Power Torque Screwdrivers Series OPERATION AND MAINTENANCE MANUAL SKC-PTA-BS12 SKC-PTA-BS12S1 Rechargeable -TYPE Automatic Brushless Series KILEWS INDUSTRIAL CO., LTD. http://www.kilews.com Y2F228A-E-001...
-
Page 3: Icon Instructions
Before you use the Cordless Screwdriver for the first time, it is essential to read and understand the manual completely (including the spare parts view). The term “Cordless Screwdriver” in all of the warning listed below refers to your main operated appliance Icon Instructions 1. - Page 4 Warning Read all instructions and make sure the appearance of the device has no damage before you use it. Failure to follow all instructions listed below may result in electric shock fire and/or serious injury. 1. Keep the working area nice and clean. 1.1 Mess and dark areas may cause of accidents.
- Page 5 17. It is necessary for the operators to read and follow up all the operating instructions in this manual. KILEWS is not responsible for any personal injury that might cause of disobeying the safety advices. 18. Use a safety device. Wear protective earmuffs to reduce personal injury Noise: The typical A-weighted noise level acc.
- Page 6 2. Do not attempt to disassemble or reassemble the device it may result in poor performance or danger of injury, the warranty applies only to initial package. 3. Do not repair the device with other than genuine KILEWS replacement parts may result in poor performance or danger of injury, the warranty will be considered void.
- Page 7 Follow belw steps to correctly install & remove battery. Insert Battery Steps Remove Battery Steps (1) Press the release button and take it out of the (1) Take screwdriver and battery. Device. Battery Release Button (2) Insert the rechargeable battery into the device (2) Follow the arrow direction.
-
Page 8: Function / Operating Introduction
Function / Operating Introduction Function Name Table Description Description Trigger Switch Torque Fixing Ring/Coupler Forward/Reverse Lever S Waist Hook Bit Sleeve OK/NG/Power/Hi&Lo Indicating Light Torque Fixing Ring battery... -
Page 9: Manual / Function
Lo for slowest rotation. It's possible that the uncompleted shut-off occurs when the switch is setup to Lo and the presetting torque is more than 50% of torque range. Please refer to the following table. Lo Switch Shut-off SKC-PTA-BS12 SKC-PTA-BS12S1 0.6( N.m )↓ 0.6( N.m )↓... - Page 10 (3) Bit Sleeve To Switch the bit and compatibility, pull the head of the type B screwdriver, and install the bit according to the diagram below, and push it in following the arrow indicated on the diagram. Pull the bit holder Insert the bit (4) Torque Adjustment Ring: Turn torque adjust ring counter clock wise to increase torque output, on the other hand decrease...
- Page 11 (7) OK/NG/Power/Hi&Lo Indicating Light Explanation Release Screw Current switch to reaches set Start Screw NG Signal Indicator stop running torque Protection Sound Judgment Signal Indicator Running green green lights lights Stop blue blue blue blue blue lights lights lights lights lights Beep Sound 1 short...
-
Page 12: Other Cautions
3. KILEWS is not responsible for any poor performance or damage caused by customers own modification of the tool. 4. It is necessary for the management to have every operator to read and follow all instructions in this manual. -
Page 13: Specifications
Specifications SKC-PTA-BS12 SKC-PTA-BS12S1 MODEL INPUT VOLTAGE(DC) DC 7.2V 0.2-1.2 0.2-1.2 hard joints TORQUE (N.m) 0.2-0.96 0.2-0.96 soft joints 80%↓ Torque accuracy (%) ±3% Torque adjustment Stepless Duty cycle 1.0s ON 3.0s OFF 1000 Unloaded Speed (min )±10% Machine 1.6~3.0 1.6~3.0... -
Page 14: Torque Adjustment Operation
In reverse rotation, the clutch is turned off when a screw is tightened at large torque, set same or higher torque to unscrew. The number from zero to eight on the Torque Scale are reference number only and not an indication of actual torque output. Please refer to Kilews website http://www.kilews.com for the detail component list..
