Kilews IMPACT Series Operation And Maintenance Manual
Hide thumbs
Also See for IMPACT Series:
- Operation and maintenance manual (13 pages) ,
- Operation and maintenance manual (11 pages) ,
- Operation and maintenance manual (11 pages)
Related Manuals for Kilews IMPACT Series
Summary of Contents for Kilews IMPACT Series
- Page 1 IMPACT SERIES Cordless Screwdriver OPERATION AND MAINTENANCE MANUAL SKC-PTI-100B KILEWS INDUSTRIAL CO., LTD. http://www.kilews.com Y2F135A-E-002...
-
Page 2: Icon Instruction
Please read manual carefully before operating the rechargeable impact screwdriver. Icon Instruction Read manual Warning Recycle Indoor use only No humidity No fire No disassemble No disposal CE certificate Accessories Item Quantity Unit Manual Guarantee Card Waist hook Screw M3*0.5P*10LT Socket Extension BIT(B) - Page 3 Warning Read all instructions and make sure the appearance of the device has no damage before you use it. Failure to follow all instructions listed below may result in electric shock fire and/or serious injury. 1. Keep the working area nice and clean. 1.1 Mess and dark areas may cause of accidents.
-
Page 4: Function Of Cordless Protection
Do not attempt to disassemble or reassemble the device at will which may result in poor performance or danger of injury, the warranty applies only to initial package. Do not repair the device with other than genuine KILEWS replacement parts may result in poor performance or danger of injury, the warranty will be considered void. - Page 5 2.1. Below illustration is showing the process of correct install & disassemble the rechargeable battery. The beep sound comes along with a flash while the screwdriver is supplied genuine battery installation. It could be operated once the battery has been identified. 2.2.
- Page 6 Appearance Functions Introduction Function Name Table Description Description Start/Stop Switch Tool Wristband Forward/Brake/Reverse Switch Belt Clip Working LED Light Tighten/Battery Status LED Bit Holder Torque Adjustment Button...
-
Page 7: Manual Functions
Manual / Functions 1. Impact cordless screwdriver Screws are continually fastened up while come along with clutch PA-PA-PA sound until the device reaches Of Five control The Stop time. (1) Trigger switch The LED lights on when the trigger switch has been pressed about one-third down, and then the screwdriver starts functioning when the switch trigger has been pressed half way down;... - Page 8 (5) Tool wristband Use wristband with tool for more convenient and safer operation and store. (6) Belt Clip Use belt clip to fix tool for more convenient and safer operation and carry. (7) Buzzer beep and LED light indicating descriptions: Operation status LED Lights Buzzer Beep...
-
Page 9: Other Cautions
Description of battery and charger 1. KILEWS SKC-LB1820B series of batteries as options to fit in the device; you may consult with local agent based on your task requirement. 2. The use of other than genuine KILEWS batteries or screwdrivers can’t be active due to the build-in protection system enforce no charging. -
Page 10: Specifications
Specifications MODEL SKC-PTI-100B Input Voltage DC 18V 0~20 0~40 Bit torque(N.m) 0~60 0~80 0~100 Rev speed at no load 0~2300 n0: (r/min) )±10% Impact rate (B.P.M) 0~3000 Weight (Kg) 1kg( battery not include ) 155 mm ＊ 195mm Length (mm) （L＊H battery not include ）...
