Ispring UVF11A Installation Instructions & User Manual page 9

Step 6. Insert the two pins of one end of the UV lamp into the female end of the blue cable.
Step 7. Carefully insert the UV lamp and the blue cable into the quartz tube. Hand-tighten
the open end nut onto the reactor chamber.
Step 8. Insert the male end of the blue cable into the indented female end of the lamp
socket of the ballast.
Step 9. Insert the two pins of the other end of the UV lamp into the protruding female end
lamp socket of the ballast.
