- Page 1 CRO1000 Commercial Grade 1000 GPD Reverse Osmosis System INSTALLATION INSTRUCTIONS & OPERATING MANUAL Ver. 06/2020 Copyright ©2005-2019 ISPRING WATER SYSTEMS, LLC. All rights reserved.
- Page 2 From various residential water filtration systems that purify your water in everyday life, to drinking water faucets that deliver pure, healthy, and tasty water to you and your family, iSpring strives for high standard products and aims to make excellent drinking water accessible for all households.
-
Page 3: Table Of Contents
Prior to Installation Read this instruction manual carefully prior to installation. Keep this manual readily available for future reference. Table of Contents Important User Information..................3 Packing List and Components..................4 Product Features Scope and Intended Use....................7 Water Treatment Process....................7 Product Dimensions....................... -
Page 4: Important User Information
Users must adhere to the installation specifications described in this Product Installation and Operation Manual (hereinafter referred to as the “instruction manual”). iSpring Water Systems LLC (Hereinafter referred to as “iSpring) is not responsible for damage, loss, or injury resulting from neglect, improper maintenance, or unauthorized modification of the unit. -
Page 5: Packing List And Components
Packing List and Components N.O. Name Quantity Image Machine Head Machine Head Assembly (with O-ring x4, 3/8" PE Shown in Figure. 1-3 tubing – 32mm pre- assembled.) 1000 GPD Reverse Osmosis Membrane Automatic Shutoff Components Housing Wrench Shown in Figure. 1-3 PP Sediment Filter with Shown in Figure. - Page 6 M8 x45 Screw sets M6 x14 Screw sets Zip tie 1/4" Quick-Fitting Lock Clip 3/8" Quick-Fitting Lock Clip Spare parts pack Figure 1. Product Components Page 5 www.123filter.com | (678) 261-7611 | support@123filter.com...
- Page 7 Figure 2. Machine Head Figure 3. Machine Head www.123filter.com | (678) 261-7611 | support@123filter.com Page 6...
-
Page 8: Product Features
2). Water Treatment Process Municipal Tap Water → PP Sediment Filter → Carbon Block Filter → Carbon Block Filter → Reverse Osmosis Membrane → Pure Water Specifications Model No. CRO1000 Inlet Water Pressure Range* 80 -130 psi Optimal Inlet Water Pressure 100 psi Inlet Water Temperature 41–100°F... -
Page 9: Product Assembling And Installations
Ensure there is enough space at the desired location for the system and to change filters safely. Contaminated water will run out of the drain line, so be sure to consider this. Verify no parts are missing from the package. Contact iSpring if any part is missing or defective. -
Page 10: Assembling The System Body
Figure 6. Machine Head Assembling 3). Assembling the System Body The 4 Omni wheels are locked onto the frame base, and the foot brake can be pressed down into the locked position for subsequent installation. Insert three frame pillars into the three square slots of the frame base. Pay careful attention to the opening direction of the frame pillars, as it is the same as the opening direction of the frame base. - Page 11 The pure water inlet is connected to the quick connector in the middle of the membrane housing cap, and the outlet is connected to water-using equipment such as a pure water faucet. The wastewater inlet is connected to the quick connector on the outside of the membrane housing cap, and the outlet discharges sewage through the sewage pipe.
- Page 12 Figure 8. How to Use the Push to Connect Fittings Page 11 www.123filter.com | (678) 261-7611 | support@123filter.com...
- Page 13 Wrench for tightening the housing 3. Put the machine head on the three frame pillars and Blue pure water tube, screw in the M6 connect to the 3/8'' quick screws. connect fitting. White drain line 4. Install PP and CTO in order from 6.
-
Page 14: Using The System
Using the System 1). Initial Setup It is essential to flush the system to avoid damage to the reverse osmosis membrane. Flushes should be performed each time the filters are changed as well. Disconnect the PE tubing between the 3 stage and the membrane housing. -
Page 15: Daily Maintenance And Filter Replacement Schedule
Ball Valve Off (during normal use) Ball Valve On (rinse) Water Flow Figure 11. Valve Position The system is now ready to use. Make sure the drain line is in position for proper wastewater dispense. 2). Daily Maintenance and Filter Replacement Schedule ... -
Page 16: Recommendations And Tips
Figure 12. How to Use the Housing Wrench To replace the RO membrane, turn off the inline water supply, drain the remaining water in the system. The membrane housing comes with 1 cap on each end, and membrane can be replaced from either end thus only one cap is needed to be removed. -
Page 17: Warranty And Registration
Warranty Registration 123filter.com To register your product for the warranty, visit our website at and go to the “Warranty” tab. We provide a 30-day money-back guarantee, a 1-year manufacturer warranty, and lifetime tech support for all of our products. However, we do not have the order information from websites other than 123Filter.com (Amazon, Home Depot, etc.), so please be sure to fill in that information upon registration of your system. - Page 19 3020 Trotters Parkway Alpharetta, GA 30004, USA iSpringFilter.com For questions, comments, or technical support, please contact us at: support@123Filter.com (678) 261-7611 Monday-Friday 8:30 a.m. - 5:30 p.m. EST...
