To tilt the motor unit [ Fig. O9 ]:
For trimming at high and low level, the motor unit
an angle of 75° to – 60° in 15° increments.
1. Keep both orange buttons
the desired direction.
2. Release both orange buttons
To extend the telescopic tube [ Fig. O10 ]:
For cutting at high and low heights, the telescopic pipe
continuously extended by up to 50 cm.
(5)
1. Loosen the orange nut
2. Extend the telescopic tube
3. Tighten the orange nut
(5)
To start the hedge trimmer [ Fig. O1 /O11 /O12 ]:
DANGER! Risk of injury!
Risk of injury if the product does not stop when you
release the start lever.
v Do not bypass the safety devices or switches. For example do
not attach the start lever to the handle.
To start:
The product is provided with a two-switch safety device (start
lever with starting lockout) to prevent the product from being
turned on by accident.
(B)
1. Put the battery
into the battery holder
2. Remove the protective cover from the blade.
3. Hold the hedge trimmer with one hand on the insulated gripping
surface on the telescopic tube
(6)
handle
.
4. Slide the starting lockout
The hedge trimmer starts and the battery charge status indication
is displayed for 5 seconds.
5. Release the starting lockout
To stop:
1. Release the start lever
(8)
.
The hedge trimmer stops.
2. Slide the protective cover over the blade.
(A)
3. Push the locking button
battery holder
(D)
.
4. MAINTENANCE
DANGER! Risk of injury!
Cut injury when the product starts accidentally.
v Wait for the blade to stop, remove the battery and slide
the protective cover over the blade before you maintain
the product.
To clean the Hedge Trimmer:
DANGER! Risk of injury!
Risk of injury and risk of damage to the product.
v Do not clean the product with water or with a water jet
(in particular high-pressure water jet).
v Do not clean with chemicals including petrol or solvents.
Some can destroy critical plastic parts.
The airflow slots must always be clean.
1. Clean the hedge trimmer with a damp cloth.
2. Clean the airflow slots with a soft brush (do not use a screwdriver).
3. Lubricate the blade with a low viscosity oil.
Avoid contact with the plastic parts.
To clean the battery and the battery charger:
Make sure that the surface and the contacts of the battery and the battery
charger always are clean and dry before you connect the battery charger.
Do not use running water.
32420-85.960.01.indd 7
32420-85.960.01.indd 7
(1)
can be tilted at
(4)
(1)
pushed and tilt the motor unit
(4)
(1)
and let the motor unit
engage.
(2)
can be
.
(2)
to the desired length.
again.
(D)
until it audibly engages.
(2)
and with the other hand on the
(7)
forward and pull the start lever
(8)
(7)
.
(B)
and remove the battery
from the
v Battery charger: Clean the contacts and the plastic parts with a soft
and dry cloth.
v Battery: Occasionally clean the ventilation slots and the terminals on
the battery using a soft brush that is clean and dry.
in
5. STORAGE
To put into storage:
The product must be stored away from children.
1. Slide the protective cover over the blade.
2. Remove the battery.
3. Charge the battery.
4. Clean the hedge trimmer, the battery and the battery charger
(see 4. MAINTENANCE).
5. Store the hedge trimmer, the battery and the battery charger in a dry,
enclosed and frost-free place.
Disposal:
(in accordance with RL2012/19/EC / S.I. 2013 No. 3113)
The product must not be disposed of to normal household
waste. It must be disposed of in line with local environmental
regulations.
IMPORTANT!
v Dispose of the product through or via your municipal recycling
collection centre.
Disposal of the battery:
The FLYMO battery contains lithium-ion cells that should not be
disposed of with normal household waste at the end of its life.
.
Li-ion
(P)
IMPORTANT!
v Dispose of the batteries through or via your municipal recycling
collection centre.
1. Discharge the lithium-ion cells completely (contact the FLYMO Service).
2. Protect the contacts on the lithium-ion cells against short circuits.
3. Dispose of the lithium-ion cells properly.
6. TROUBLESHOOTING
DANGER! Risk of injury!
Cut injury when the product starts accidentally.
v Wait for the blade to stop, remove the battery and slide the
protective cover over the blade before you troubleshoot the
product.
Problem
Hedge trimmer can no
longer be stopped
Hedge is not cleanly cut
Hedge trimmer vibrates
severely
Hedge trimmer does not
start or stops.
(L1)
LED
is flashing
green [ Fig. O4 ]
Hedge trimmer does not
start or stops.
(Wp)
Error-LED
is illuminated
red [ Fig. O4 ]
Hedge trimmer does not
start or stops.
(Wp)
Error-LED
is flashing red
[ Fig. O4 ]
Possible Cause
Remedy
Start lever is stuck.
v Remove the battery and
loosen the start lever.
Blade is blunt or damaged.
v Let the blade replaced by the
FLYMO Service.
Blade is damaged.
v Switch off the product and
let the blade be replaced.
Battery is empty.
v Charge the battery.
Battery temperature is outside
v Wait until the battery tem
the permissible temperature
perature is between
range.
0 °C – + 45 °C again.
There are drops of water or
v Remove the water drops /
moisture between the battery
moisture with a dry cloth.
contacts on the hedge trimmer.
Engine is blocked.
v Remove the obstacle.
Start again.
Product is defective.
v Contact the FLYMO Service.
7
