This manual contains important safety information
concerning the maintenance, use and operation
of this product. Failure to follow the instructions
contained in this manual may result in serious injury.
If you are unable to understand the contents
of this manual, please bring it to the attention
of your supervisor. Do not operate this equipment
unless you have read and understood the contents
of this manual.
GLO-RAY
Heated Display Cases
GRCD & GRHD Series
Installation &
Operating Manual
I & W #07.05.080.00
®
Este manual contiene importante información sobre
seguridad concerniente al mantenimiento, uso
y operación de este producto. Cualquier falla
en el seguimiento de las instrucciones contenidas en
este manual puede resultar en un serio daño. Si usted
no puede entender el contenido de este manual por
favor pregunte a su supervisor. No opere este equipo
al menos que haya leído y comprendido el contenido
de este manual.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hatco Glo-Ray GRCD-1P
Summary of Contents for Hatco Glo-Ray GRCD-1P
- Page 1 Heated Display Cases GRCD & GRHD Series This manual contains important safety information concerning the maintenance, use and operation of this product. Failure to follow the instructions contained in this manual may result in serious injury. If you are unable to understand the contents of this manual, please bring it to the attention of your supervisor.
-
Page 2: Table Of Contents
Serial No. Voltage Date of Purchase INTRODUCTION Hatco Glo-Ray Heated Display Cases are designed to hold prepared foods for prolonged periods of time while maintaining that “just made” quality. Hatco Display Cases provide the best environment for food products by regulating the air temperature. Display models equipped with humidity control also balance the humidity level. -
Page 3: Important Safety Instructions
IMPORTANT! Read the following important safety instructions to avoid personal injury or death, and to avoid damage to the equipment or property. WARNINGS To avoid any injury, turn the power switch OFF, unplug the unit from the power source and allow to cool before performing any maintenance. - Page 4 Some aftermarket or generic replacement parts do not have the characteristics that will allow them to operate safely in Hatco equipment. It is essential to use Hatco Replacement Parts when repairing Hatco equipment. Failure to use Hatco Replacement...
-
Page 5: Model Descriptions
4" (102 mm) appliance legs, and a cord and plug set. GRCD-1P (Single Tier) The GRCD-1P is designed to hold up to one standard full size food pan. The unit has one hinged door. GRCD-1PD (Dual Tier) -
Page 6: All Grhd Models
MODEL DESCRIPTIONS ALL GRHD MODELS All GRHD models are constructed of stainless steel and aluminum with sliding doors on the back side, and full view tempered glass sides. The display cases feature a thermostatically controlled heated base, infrared upper heating elements, incandescent lights, 4"... -
Page 7: Specifications
ELECTRICAL RATING CHART - GRCD MODELS Model Voltage GRCD-1P 220-230CE 230-240CE GRCD-1PD 220-230CE 230-240CE GRCD-2P 220-230CE 230-240CE GRCD-2PD 220-230CE 230-240CE GRCD-2PDG GRCD-3P 220-230CE 230-240CE GRCD-3PD 220-230CE 230-240CE GRCD-3PDG * NEMA 5-20P for Canada. Not available for Canada with Backlit Base Sign Holder. - Page 8 SPECIFICATIONS ELECTRICAL RATING CHART - GRCD MODELS Model Voltage GRCDH-1P 220-230CE 230-240CE GRCDH-1PD 220-230CE 230-240CE GRCDH-2P 220-230CE 230-240CE GRCDH-2PD 220-230CE 230-240CE GRCDH-2PDG GRCDH-3P 220-230CE 230-240CE GRCDH-3PD 220-230CE 230-240CE GRCDH-3PDG * NEMA 5-20P for Canada. Not available for Canada with Backlit Base Sign Holder. †...
-
Page 9: Electrical Rating Chart-Grhd Models
ELECTRICAL RATING CHART - GRHD MODELS Model Voltage GRHD-2P 220-230CE 230-240CE GRHD-2PD 220-230CE 230-240CE GRHD-3P 220-230CE 230-240CE GRHD-3PD 220-230CE 230-240CE GRHD-4P 120/208 120/240 220-230CE 230-240CE GRHD-4PD 120/208 120/240 220-230CE 230-240CE * NEMA 5-20P for Canada. Not available for Canada. ‡ The electrical information in the shaded areas pertains to Export models only. - Page 10 SPECIFICATIONS ELECTRICAL RATING CHART - GRHD MODELS Model Voltage GRHDH-2P 220-230CE 230-240CE GRHDH-2PD 220-230CE 230-240CE GRHDH-3P 220-230CE 230-240CE GRHDH-3PD 220-230CE 230-240CE GRHDH-4P 120/208 120/240 220-230CE 230-240CE GRHDH-4PD 120/208 120/240 220-230CE 230-240CE * NEMA 5-20P for Canada. Not available for Canada. ‡...
-
Page 11: Plug Configurations
DIMENSIONS - GRCD MODELS Model (A) Width (B) Length (C) Height* GRCD-1P 26" 20-5/8" (660 mm) (524 mm) GRCD-1PD 26"... -
Page 12: Dimensions-Grhd Models
SPECIFICATIONS DIMENSIONS - GRHD MODELS Model (A) Width (B) Length (C) Height* GRHD-2P 26" 32-1/2" (660 mm) (826 mm) GRHD-2PD 26" 32-1/2" (660 mm) (826 mm) GRHD-3P 26" 45-1/2" (660 mm) (1156 mm) GRHD-3PD 26" 45-1/2" (660 mm) (1156 mm) GRHD-4P 26"... -
Page 13: Installation
ALL MODELS CAUTION The National Sanitation Foundation (NSF) requires units over 36" (914 mm) in length or weighing more than 80 lbs. (36 kg) to be either sealed or raised on the installation surface. If this unit cannot be sealed at the point of use, 4" (102 mm) legs are included to allow for proper cleaning access below unit. -
Page 14: Grhd Models
INSTALLATION GRHD MODELS 1. Remove plastic bag containing 4 adjustable legs from inside the unit. 2. Remove all components from inside the unit. See Figure 10. 3. Remove all doors by grasping the door edges then lifting up and out of the bottom channel. See Figure 10. -
Page 15: Location
LOCATION - ALL MODELS CAUTION The unit must be transported in an upright position. If laid on its side, all glass surfaces, pans rails and skirts must be secured with tape, and water must be removed from the unit. CAUTION To prevent any injury or damage locate the unit at the proper counter height, in an area that is convenient for use. -
Page 16: Operation
On dual tier models, the Top and Center Heat Indicators will light when controls are in the ON position. NOTE: Temperature settings may vary depending upon product make-up and consistency. 4. Allow unit 30 minutes to reach operating temperature. HATCO GLO-RAY Base Heat Control... -
Page 17: Humidified Models
8. Allow unit 30 minutes to reach operating temperature. 9. At the end of the day or shift, turn unit off and allow to cool down. Remove and clean the water trough. Form No. GRCD/HDM-0703 OPERATION Center Heat Control* HATCO GLO-RAY Base Heat Control... -
Page 18: Maintenance
MAINTENANCE GENERAL Hatco Glo-Ray Heated Display Cases are designed ® for maximum durability and performance, with minimum maintenance. WARNING To avoid any injury, turn the power switch OFF, unplug the unit from the power source and allow to cool before performing any maintenance. -
Page 19: Display Light Bulb Replacement
NOTE: Hatco shatter-resistant light bulbs meet N.S.F. standards for food holding and display areas. For 120, 120/208 and 120/240 Volt applications, use Hatco part #02.30.043.00. For 220 or 240 Volt applications, use Hatco part # 02.30.058.00. WARNING Only light bulbs which meet or exceed N.S.F. -
Page 20: Accessories
ACCESSORIES SLANT LEG KIT (GRHD Models Only without Humidity) The Slant Leg Kit tilts the unit in a forward position for optimum display of food product. 1. Remove the pan rail or sandwich chutes. 2. Carefully lay unit on its side (requires two people). CAUTION Do not lay unit on the side with the control panel or the front of a curved glass unit, damage to unit... - Page 21 DESIGNER COLORS Choose an optional Designer color in place of the stainless steel exterior finish to match your décor. DOUBLE-SIDED OPENING (GRHD Models Only) GRHD models can be configured for double-sided opening by installing the optional front doors. SLIDING OR FLIP-UP STYLE DOORS (GRHD Models Only) Sliding or flip-up style doors are available.
-
Page 22: Hatco Limited Warranty
Hatco reserves the right to accept or reject any such claim in whole or in part. Hatco will not accept the return of any Product without prior written approval from Hatco, and all such approved returns shall be made at Buyer’s sole expense. - Page 23 NOTES Form No. GRCD/HDM-0703...
-
Page 24: Authorized Parts Distributors
NEW YORK GCS Service Acme American Repairs, Inc. Indianapolis 317-545-9655 Brooklyn Parts & Service Fax (800) 690-2966 Printed in U.S.A. July 2003 HATCO AUTHORIZED PARTS DISTRIBUTORS NEW YORK (continued) Alpro Service Co. 319-323-1823 Brooklyn Appliance Installation Buffalo Northern Parts Dist.
