ipf electronic IV56E205-S Quick Start Manual

IN32E332-S
Inductive proximity switsch
IV56E205-S
Amplifier
VKC0E333-S
Cable socket

Installation of the sensor

•
The sensor IN32E332-S is an inductive proximity switch for non-flush mounting. Due to its construction,
the device only detects metallic objects.
• To achieve the nominal switching distance of 15mm (see technical data), must have the metal part
following properties:
For other materials, the correction factors are listed in the technical data.
• The switching distance may deviate from the nominal value by ±20% due to component tolerances.
• Install the device in a way, that the plastic cap is not surrounded by metal. The lateral distance to metallic
objects must be at least 32mm.
• To avoid damaging the threaded sleeve during assembly, the tightening torque must not exceed 150 Nm.
• The device may be used in surroundings with temperatures up to 230°C.

Installation of the amplifier

• The amplifier IV56E205-S is to be used for the operation of the sensor IN32E332-S in connection with the
cable socket VKC0E333-S.
• The device is suitable for mounting on a DIN rail. Mounting must take place outside the dust-ex-area, e.g.
in a protected switch cabinet.
• The pnp switching output can be further processed with a PLC. The switching output has a switch-on delay
of 100ms.

Elektrical connection

Connection of the sensor to the amplifier via the
VKC0E333-S cable socket:
Connection of the operating voltage and the switching
output to the amplifier.
IMPORTANT:
• Switch off the operating voltage before connecting or disconnecting the amplifier!
• The cable socket may also only be plugged in or unplugged from the sensor when it is de-energized. An
appropriate waiting time (>10s) must be observed before pulling off.
• When plugging in the cable socket, make sure that, that it snaps securely into the connector of the sensor.
ipf electronic gmbh │ Rosmarter Allee 14 • 58762 Altena • Germany │ Tel +49 2351 9365-0 • info@ipf-electronic.com • www.ipf-electronic.com
Material: ST37
Dimensions:
MANUAL • Subject to alteration! Version: 07.01.2022
32mm x 32mm x 1mm
Clamp 4: brown (sensor power supply +3V)
Clamp 5: black (screen)
Clamp 6: blue (sensor power supply GND)
Clamp 9: + U
B
Clamp 8: switching output pnp, no, 400mA
Clamp 7: 0V (GND)
1
