Installation & Operations Manual
Emergency Pedestal Phone
• 2100-PLL Landline 12v Pedestal
• 2100-PLC Cellular 12v Pedestal
• 2100-PL9 900 MHz 12v Pedestal
• 2100-PLT 2-Way Radio 12v Pedestal
N56W24720 N. Corporate Circle
Sussex, WI 53089
RP8500PLL
Made in the USA
Ver. 6
800-451-1460
www.rathcommunications.com
2 Year Warranty
10/17
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rath 2100-PL9 900 MHz 12v Pedestal
Summary of Contents for Rath 2100-PL9 900 MHz 12v Pedestal
- Page 1 Installation & Operations Manual Emergency Pedestal Phone • 2100-PLL Landline 12v Pedestal • 2100-PLC Cellular 12v Pedestal • 2100-PL9 900 MHz 12v Pedestal • 2100-PLT 2-Way Radio 12v Pedestal N56W24720 N. Corporate Circle Sussex, WI 53089 RP8500PLL Made in the USA Ver.
-
Page 2: Table Of Contents
Thank you for purchasing RATH’s Pedestal Phone. We are the largest Emergency Communication Manufacturer in North America and have been in business for over 35 years. We take great pride in our products, service, and support. Our Emergency Products are of the highest quality. -
Page 3: Description
Description Figure 1: Front & Back View Features: • ADA compliant (hands free operation) • LED call status indicator • Powder coated steel construction inside and out • Aluminum access panels powder coated inside and out • Weather and vandal resistant •... -
Page 4: Items Needed
Items Needed for Installation • 1/4” spanner adapter (provided to remove access panels) • Concrete for 16” deep, 2’ diameter • RATH® Kit 7476* or 7477** • Adjustable wrench • #1 Phillips screwdriver • Analog phone line (if using 900 MHz or a Landline) •... - Page 5 4. When the “PWR”, “RDY”, and “NW” lights on the front of the unit are illuminated, unit is ready. 5. Verify SmartPhone is plugged into the FXS port on Cellular Module. Note: If the SIM card is not provided to RATH® at time of purchase, an active SIM Card will need to be installed into SIM Card slot.
-
Page 6: Phone Programming
Phone Programming 1. You can program the phone on-site or remotely. Note: Cellular and 900 MHz applications cannot be remotely programmed. 2. If programming on-site, open back Access Panel 1. Use the #10 spanner bit provided to remove the 6 security screws. -
Page 7: Phone Testing
If you have answered YES to all questions, you have successfully installed and tested the phone. If you answer NO to any question, proceed to the Troubleshooting Section. *RATH® recommends the Pedestal be tested on a regular basis to ensure proper operation. Adjusting the Volume If the volume is too low or high, adjust it by referring to the diagram and instructions below. -
Page 8: Troubleshooting
Troubleshooting Problem Possible Cause & Solutions No dial tone when the • Check to make sure the phone line is connected to SmartPhone board. button is pushed: • Verify dial tone and voltage on phone line going into unit. Audio is low from the speaker: •... -
Page 9: Wiring
Wiring Page 9...
