Installation & Operations Manual
36" Emergency Call Station
• 2100-CDC Cellular Dusk2Dawn Call Station
• 2100-CDL Landline Dusk2Dawn Call Station
• 2100-CD9 900 MHz Dusk2Dawn Call Station
• 2100-CDT 2-Way Radio Dusk2Dawn Call Station
• 2100-CDV VoIP Dusk2Dawn Call Station
• 2100-CDW Wi-Fi VoIP Dusk2Dawn Call Station
N56W24720 N. Corporate Circle
Sussex, WI 53089
RP8500CD
Made in the USA
Ver. 4
800-451-1460
www.RATHCommunications.com
2 Year Warranty
10/17
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rath 2100-CD9
Summary of Contents for Rath 2100-CD9
- Page 1 36” Emergency Call Station • 2100-CDC Cellular Dusk2Dawn Call Station • 2100-CDL Landline Dusk2Dawn Call Station • 2100-CD9 900 MHz Dusk2Dawn Call Station • 2100-CDT 2-Way Radio Dusk2Dawn Call Station • 2100-CDV VoIP Dusk2Dawn Call Station • 2100-CDW Wi-Fi VoIP Dusk2Dawn Call Station N56W24720 N.
-
Page 2: Table Of Contents
Thank you for purchasing RATH’s Dusk2Dawn Call Station. We are the largest Emergency Communication Manufacturer in North America and have been in business for over 35 years. We take great pride in our products, service, and support. Our Emergency Products are of the highest quality. -
Page 3: Description
Description Features: Figure 1: Front & Back View • ADA compliant (hands free operation) • LED call status indicator 8” 10” 1-9/16” • Powder coated aluminum construction 3” • NEMA 4 enclosure for electronics • Conduit holes for easy installation •... -
Page 4: Items Needed
If Mounting to Wall Pole Mount Bracket (Part # RP7700098A) If Mounting to Pole #1 Phillips Screwdriver Voltage Meter Security Torx Bit Provided by RATH® Adjustable Wrench 120v Power Source Analog Phone Line If Using Landline Phone Cable If Using Landline Installation 1. - Page 5 5. Verify SmartPhone is plugged into the FXS port on Cellular Module. Note: If the SIM card is not provided to RATH® at time of purchase, an active SIM Card will need to be installed into SIM Card slot. When installing SIM Card, disconnect power from cellular unit, install SIM Card in SIM Card slot, then reapply power.
-
Page 6: Phone Programming
Phone Programming 1. You can program the phone on-site or remotely. Note: Cellular and 900 MHz applications cannot be remotely programmed. 2. If programming on-site, remove 12 security screws from unit, remove top cap, and pull front assembly away from back unit. 3. -
Page 7: Phone Testing
If you have answered YES to all questions, you have successfully installed and tested the phone. If you answer NO to any question, proceed to the Troubleshooting Section. *RATH® recommends the Call Station be tested on a regular basis to ensure proper operation. Adjusting the Volume If the volume is too low or high, adjust it by referring to the diagram and instructions below. -
Page 8: Troubleshooting
Troubleshooting Problem Possible Cause & Solutions No dial tone when the button is • Check to make sure the phone line is connected to SmartPhone board. pushed: • Verify dial tone and voltage on phone line going into unit. Audio is low from the speaker: •... -
Page 9: Wiring
Wiring 277vac Source Connects to H1, H6 and Ground on the Transformer. 480vac Source Connects to H1, H4 Optional and Ground on the Transformer. Photocell Strobe Transformer (Only if using 277 or 480vac power) FRONT Strobe COVER Constant Positive 120vac Negative Charging/Finishing/Ready Ground...
