- Page 1 Installation & Operations Manual Emergency Call Box 2100-986DA 2100-986DAI N56W24720 N. Corporate Circle Sussex, WI 53089 RP85000986DA Made in the USA Ver. 5 800-451-1460 www.rathcommunications.com 2 Year Warranty 07/19...
- Page 2 Installation ....... . . Page 3 2100-986DA Wiring ......Page 4 Phone Programming .
- Page 3 Installation Items Needed: • Live phone line • 120vac power • Drill • Drill bit or knockout set • Biscuit jack • Mounting screws • #10 spanner bit (provided) • Conduit with (2) water tight connectors • Screwdriver • Wire nuts •...
- Page 4 2100-986DA Wiring Phone Line RJ11 Connection White Wire, Neutral Black Wire, Phone Programming Please choose one of the options below that matches the type of line that the phone is installed on: 1. Standard Telephone Line Programming a. Press ENTER to begin programming b.
- Page 5 Program Location Message (Optional): RATH® phones have the ability to play a location message when the call is answered. This feature is used when the phone is calling a phone number that cannot identify where the call is coming from by caller ID, or needs more location information than caller ID can provide.
- Page 6 2100-986DAI Wiring 1. Mount the strobe to a wall or pole using the proper anchor screws. 2. Run two wires from the phone to the strobe. 3. Attach the wires to the strobe using two wire nuts. 4. Connect the hot incoming wire to the transformer and the NO terminal on the relay board. 5.
- Page 7 Troubleshooting Problem Possible Cause & Solutions No dial tone when the • Check to make sure the phone line is connected. button is pushed: • Verify dial tone and voltage on phone line going into unit. Audio is low from the speaker: •...
