Figure 1: Sampling Module Block Diagram; Figure 2: Sampling Module, 80E04 Shown - Tektronix 80E02 User Manual

SELECT channel button
TDR on indicator
light (red)
(80E04)
Hold-down screw
Signal connector
80E00 Electrical Sampling Modules User Manual
Sampler
Strobe
Generator
Note: the 80E01and 80E06 are
single channel modules with a
dedicated strobe drive and
generator.
Sampler

Figure 1: Sampling module block diagram

Channel indicator
light (yellow)
Left channel

Figure 2: Sampling module, 80E04 shown

50 Ω
To main instrument
Strobe drive
From main instrument
To main instrument
50 Ω
TEKPROBE connector
Right channel
Getting Started
3
