SELECT channel button
TDR on indicator
light (red)
(80E04)
Hold-down screw
Signal connector
80E00 Electrical Sampling Modules User Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Sampler
Strobe Strobe drive
Generator
Note: the 80E01and 80E06 are
single channel modules with a
dedicated strobe drive and
generator.
Sampler

Figure 1: Sampling module block diagram

Channel indicator
light (yellow)
Left channel

Figure 2: Sampling module, 80E04 shown

50 Ω
To main instrument
From main instrument
To main instrument
50 Ω
TEKPROBE connector
Right channel
Getting Started
3
