Product Description; Technical Data - Sonnen sonnenBatterie hybrid 9.53 Operating Instructions Manual

3 | Product description

3 Product description

3.1 Technical data

sonnenBatterie hybrid
System data (AC)
Nominal voltage
Nominal frequency
Nominal power
Rated current
Rated apparent power
Charging / Discharging power
Charging / Discharging current
Power factor range
Max. efficiency (battery to grid)
Max. efficiency (PV to grid)
Max. Impedance (Z )
MAX
Current (Max. continous)
Short-circuit current (I
SC
Max. output fault current
Inrush current
Mains connection
Max. ext. overcurrent protection
Mains topology
Mains connection fuse
Island detection mode
Photovoltaic (PV) input (DC)
Number of PV inputs / MPP Tracker
Min. input voltage
Max. input voltage
Initial input voltage
MPP voltage range
Max recommended PV input
Max. input current
Backfeed current to array
Short-circuit current (I
SC
Battery data (DC)
Cell technology
Nominal capacity
Usable capacity
Nominal voltage
Battery input voltage
1
Any oversizing of the PV input may cause a thermal derating of the inverter.
8 / 28
9.53/2,5
1,100 W
4.8 A
)
1
)
2.5 kWh
2.25 kWh
9.53/5 9.53/7,5
230 V
50 Hz
4,600 W
20 A
4,600 VA
2,500 W 3,300 W
10.9 A 14.3 A
0.8 capacitive ... 0.8 inductive
95 %
97.5 %
0.35 Ω + j0.22 Ω
20 A
40 A (< 0.2 s)
120 mA
0 A (0 s)
single-phase, L / N / PE
25 A, 1ph
TN / TT
Miniature circuit breaker | Type B | 20 - 25 A
Active method with frequency shift
75 V ... 600 V
lithium iron phosphate (LiFePO4)
5.0 kWh 7.5 kWh
4.5 kWh 6.75 kWh
48 V
44 – 54 V
Operating instructions sonnenBatterie hybrid 9.53
9.53/10 9.53/12,5
3,300 W 3,300 W
14.3 A 14.3 A
2
75 V
750 V
100 V
6,500 W
13 A
0 A
15 A
10.0 kWh 12.5 kWh
9.0 kWh 11.25 kWh
9.53/15
3,300 W
14.3 A
15.0 kWh
13.5 kWh
