- Page 1 Operating instructions | for operators sonnenBatterie eco 8.0 KD-436 • Part no. 22283 • Version 04 info@sonnen.de • sonnen.de...
- Page 2 IMPORTANT „ Read this documentation carefully before installation / operation. „ Retain this document for reference purposes. Publisher sonnen GmbH Am Riedbach 1 D-87499 Wildpoldsried Service number +49 8304 92933 444 Email info@sonnen.de Document Document number Part number 22283 Version...
-
Page 3: Table Of Contents
3.4.1 Basic principle........................ 12 3.4.2 Feed-in limit......................... 12 3.4.3 Intelligent charging management ................ 14 3.5 Function of the sonnen Eclipse.................... 16 4 Switching on the storage system ...................... 17 4.1 Switching on the grid voltage ..................... 17 4.2 Switching on the storage system.................... 17 5 Using the optional display........................ 18... - Page 4 Table of contents 9 Troubleshooting............................ 27 10 Uninstallation and disposal ........................ 28 10.1 Uninstallation........................... 28 10.2 Disposal ............................. 28 ANNEX ................................. 29 11 Manufacturer's Warranty sonnen Australia Pty Limited............ 30 Operating instructions sonnenBatterie eco 8.0...
-
Page 5: Information About This Document
Information about this document | 1 1 Information about this document This document describes the operation of the sonnenBatterie eco 8.0. „ Read this document in its entirety. „ Keep this document in the vicinity of the sonnenBatterie. 1.1 Target group of this document This document is intended for the storage system operator. -
Page 6: Safety
2 | Safety 2 Safety 2.1 Intended Use The sonnenBatterie eco 8.0 is a battery storage system which can be used to store elec- trical energy. Improper use of this system poses a risk of death or injury to the user or third parties as well as damage to the product and other items of value. -
Page 7: Voltage Inside The Storage System
Safety | 2 • The replacement of battery modules must be performed by authorised service techni- cians only. When replacing batteries, replace with the same type and number of batter- ies or battery modules. 2.4 Voltage inside the storage system The storage system contains live electrical parts, which poses a risk of electrical shock. - Page 8 2 | Safety „ Only firefighters with appropriate protective equipment (safety gloves, safety clothing, face guard, breathing protection) are permitted to enter the room where the burning storage system is located. There is a danger of electrocution when extinguishing fire while the storage system is switched on.
-
Page 9: Product Description
Product description | 3 3 Product description 3.1 Technical data sonnenBatterie eco 8.0/2,5 8.0/5 8.0/7,5 8.0/10 8.0/12,5 8.0/15 System data (AC) Nominal voltage 400 V Nominal frequency 50 Hz Nominal power 1,100 W 2,500 W 3,300 W 3,300 W 3,300 W 3,300 W Nominal current 1.6 A... -
Page 10: Type Plate
3 | Product description Degree of Protection IP30 Rated short-withstand cur- 10 kA rent(I Separation principle PV -> AC Separation principle Batt. -> AC galvanic isolation (functional insulation) Power meter Voltage measurement inputs Nominal voltage (AC): 230 V (L-N), 400 V (L-L) | max. connectible conductor cross-section: 1.5 mm²... -
Page 11: Symbols On The Outside Of The Storage System
Product description | 3 3.3 Symbols on the outside of the storage system Symbol Meaning Warning: flammable materials. Warning: hazards due to batteries. Warning: electrical voltage. Warning: electrical voltage. Wait five minutes after switching off (capacitor de-energising time). 5 min Warning: product is heavy. -
Page 12: Function
3 | Product description 3.4 Function 3.4.1 Basic principle Illustration 1: sonnenBatterie function PV system Measurement of consumption Storage system Public electrical mains Consumers in building (e. g. washing machine, hob, lamps, refrigerator, etc.) The storage system (2) is connected to the PV system (1) and the public electrical mains (5). - Page 13 Product description | 3 Example • Nominal power of PV system: 10 kWp • Power limit: 50% • Maximum feed-in power: 5 kW In this example, the feed-in power of 5 kW must not be exceeded. The following figure shows an example of the PV system’s production over the course of a day. To prevent production reduction –...
-
Page 14: Intelligent Charging Management
3 | Product description 3.4.3 Intelligent charging management The charging behaviour of the storage system is controlled via intelligent charging man- agement. The aims of this intelligent control are as follows: • Storage of the midday peak in the storage system (sufficient storage capacity must still be available for this) •... - Page 15 Product description | 3 Without intelligent charging management, the stor- age system would immediately use the surplus to charge the battery (until the maximum charging power is reached). In this example, this behaviour would result in the storage system being fully charged before midday, meaning that the surplus exceeding the feed-in limit after this point would no longer be able to be stored in the battery.
-
Page 16: Function Of The Sonnen Eclipse
3.5 Function of the sonnen Eclipse The sonnen Eclipse (light ring in the sonnen logo on the front of the storage system) indic- ates the current status of the storage system when it is switched on. The following operating statuses may be indicated:... -
Page 17: Switching On The Storage System
The storage system then starts up and performs a self-test. Once the self-test is success- ful, the storage system is ready to operate. When the storage system is in normal operation, the sonnen Eclipse pulses white (see Function of the sonnen Eclipse [P. 16]). -
Page 18: Using The Optional Display
5 | Using the optional display 5 Using the optional display The storage system is not delivered with a display as standard. Retrofitting the display is not possible. The installed display is a multi-touch screen. It can be controlled with movements of the hand (like a standard smartphone). -
Page 19: Internet Portal
6.1 Logging into the internet portal To log into the internet portal, proceed as follows: Enter the following web address in the browser: https://my.sonnen-batterie.com 2. The login window opens, as shown on the left. 3. Enter your access data, which was provided as part of the scope of delivery. -
Page 20: Using The Control Page
6 | Internet portal 6.4 Using the control page The control page contains an overview of the con- nected sonnenSmart-Plugs. „ Click on the relevant button to select a smart plug (e. g. washing machine). „ Click on the é or ê button to change the order of the smart plugs. -
Page 21: Elements Of The Power Graph
Internet portal | 6 The values displayed are subject to measuring instrument tolerances and rounding errors. The only information that is relevant in terms of your energy bills is the data taken from the utility company’s meters. 6.5.1 Elements of the power graph The power graph presents the different energy flows in relation to time. -
Page 22: Analysis Of Power Diagram
6 | Internet portal Description This legend shows which energy flows are displayed in which colour in the graph (f. e. consumption is shown in blue). „ Clicking on the desired energy flow (e.g. consumption) shows or hides this flow in the graph. -
Page 23: Analysing Pie Charts
Internet portal | 6 Description Generation has increased to approx. 3300 watts. This is used to cover consumption (blue) and charge the storage system (green) at a minimal level. Charging with higher power is prevented by the intelligent charging management system. This function ensures that storage capacity is kept free in order to store part of the midday peak in the storage sys- tem later. -
Page 24: Using The Forecast Page
6 | Internet portal Consumption pie chart The pie chart shows the power that was required in the building during the analysed time frame. Purchased power (taken from the mains) is marked in grey in the chart. The blue part represents self production. -
Page 25: Maintenance
Maintenance | 7 7 Maintenance For fault-free, safe, reliable and long-lasting operation of the storage system, it is essential to carry out regular function checks and cleaning. The battery modules installed in the storage system do not require maintenance. 7.1 Checking function Maintenance interval Action to be taken „... -
Page 26: Decommissioning
8 | Decommissioning 8 Decommissioning NOTICE Deep-discharge of the battery modules Destruction of the battery modules! „ Do not disconnect the storage system from the public grid for long periods of time. „ Never continue to operate battery modules which have been deep-dis- charged. -
Page 27: Troubleshooting
UDP Port Service 1194 1196 „ Check whether the home network The sonnen Eclipse of the storage sys- The internet connection to the storage tem pulses orange. system has been interrupted. router is able to establish an inter- net connection. -
Page 28: Uninstallation And Disposal
„ Dispose of the storage system and the batteries it contains in an environmentally friendly way through suitable collection systems. „ Contact sonnen GmbH to dispose of old bat- teries. Illustration 13: WEEE symbol 28 / 36 Operating instructions sonnenBatterie eco 8.0... -
Page 29: Annex
ANNEX | ANNEX 1. Warranty You can find the manufacturer’s warranty on the following pages. KD-436 | 22283 | EN | 04 29 / 36... - Page 30 (ii) May 2017...
- Page 31 (ii) (iii) (iv) 1510387/11...
- Page 32 1510387/11...
- Page 33 1510387/11...
- Page 36 GmbH Am Riedbach 1 D-87499 Wildpoldsried...
