- Page 1 HDR-8X8-XT User Manual 4K Ultra-HD 8X8 HDBaseT HDMI Matrix with POE Distribute 8 4K HDMI sources to 8 local HDMI monitors and 8 remote HDMI displays (16 Total) via HDBaseT with IR, and TCP/IP control support Made in U.S.A. www.SmartAVI.com...
- Page 2 TABLE OF CONTENTS WHAT'S IN THE BOX? INTRODUCTION FEATURES APPLICATIONS TECHNICAL SPECIFICATIONS HARDWARE INSTALLATION FRONT PANEL FUNCTIONS REAR PANEL REMOTE CONTROL CONTROL VIA ETHERNET 9-10 EDID HDBaseT RECEIVER IR CONTROL SYSTEM LIMITED WARRANTY STATEMENT WHAT’S IN THE BOX? PART NO. QTY DESCRIPTION HDR-8x8-XTS 4K-Ready 8x8 HDMI Matrix Switch with CAT5/6/7 HDBaseT...
- Page 3 INTRODUCTION The HDR-8x8-XT with simultaneous CAT5e/6/7 and HDMI outputs connects eight HDMI input sources to sixteen displays. This matrix features eight mirrored HDMI outputs, providing 8 HDMI output ports and 8 CAT-Cable output ports simultaneously. The HDR-8x8-XT supports the transmission of video (resolutions up to 1080p Full HD and 4Kx2K@30Hz) and supports high resolution digital audio formats such as LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio.
-
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS VIDEO HDMI Format HDMI 1.4, HDMI2.0, HDCP 2.2 and DVI1.0 compliant Video Bandwidth 297MHz[10.2Gbps] Input Resolution Up to 4K (3840x2160 @ 30Hz) Output Resolution Up to 4K (3840x2160 @ 30Hz) HDMI Connector Type A 19 pin female RJ-45 Connector WE/SS 8P8C AUDIO Audio Connectors... -
Page 5: Hardware Installation
HARDWARE INSTALLATION BASIC SETUP: 1. Turn the power off on the HDR-8X8-XT. Do not hotplug! Insert and extract cables carefully with the power switch off. Connecting and disconnecting while the HDR-8X8-XT is powered can result in dam- age to circuitry. -
Page 6: Front Panel Functions
FRONT PANEL FUNCTIONS Figure 6-1 1. LCD: Displays all information regarding individual input settings/output settings and EDID manage- ment. 2. IR: IR Receiver window (accepts only the HDR 8x8 -XT remote control signal). POWER: Press this button to power the device on/off. The LED will illuminate green when the power is on, red when it is in 'Standby' mode. -
Page 7: Rear Panel
HDX-POE-PRO HDBT receiver. For example, you can connect a control PC to the OUTPUT A, RS-232 connector on the HDR-8X8-XT. Then connect an RS-232 device to the RS-232 connector on the HDX-POE-PRO HDBT receiver connected to OUTPUT A on the HDR-8X8-XT . - Page 8 REMOTE CONTROL 1. Power on /Standby： Press this button to power on the matrix or put it in standby mode. 2. Input port selection area： Press these buttons to select input 1-8. Press the forward/backward but- tons to cycle from input 1-8. 3.
- Page 9 CONTROL VIA ETHERNET HDR-8X8-XT TCP/IP control is a feature that allows source / display switching, EDID configuration and Network settings to be controlled remotely via HTTP. Manage your HDR-8X8-XT with ease from anywhere in the world. Make sure the HDR-8X8-XT RJ45 PC Control port is connected to your network.
- Page 10 CONTROL VIA ETHERNET (Continued) The Matrix Control Page is where you switch inputs to outputs. The column running top to bottom on the left shows the 8 outputs. The Top row shows the inputs or sources. Clicking the box where the input intersects the output sets the connection.
-
Page 11: The Front Panel
Why is EDID so important with the HDR 8x8 XT ? The HDR-8x8-XT is a complex piece of technology that replicates and switches between multiple inputs and outputs. Each connected source device will require one EDID to read. EDID management is carefully handled by the HDR-8x8-XT to provide a single EDID for each source to read. - Page 12 HDBaseT RECEIVER POWER OVER ETHERNET (POE): This system can run with only the HDR-8X8-XT powered, RXs do not need to be powered. They are pow- ered via the CAT 5e/6 cable. INTERNET ACCESS for your connected devices: The RJ45 connector on the HDBaseT receiver labeled “HDBaseT IN” is for connecting to the HDR-8X8-XT.
- Page 13 IR CONTROL SYSTEM (IR Call-back of Matrix and Source Devices) IR IN/OUT: Super IR control system interface. The matrix is not only a switcher and extender of multiple HDMI signals to multiple remote HDMI receiv- ers. The HDR 8x8 XT also passes IR control signals through the IR call-back system to the matrix and HDMI sources for full, independent control of all connected inputs from output locations.
- Page 14 Smart-AVI limited warranty is valid in any country where the covered product is distributed by Smart-AVI. Limitations of warranty To the extant allowed by local law, neither Smart-AVI nor its third party suppliers make any other warranty or condition of any kind whether expressed or implied with respect to the Smart-AVI product, and specifically disclaim implied warranties or conditions of merchantability, satisfactory quality, and fitness for a particular purpose.
- Page 15 NOTICE The information contained in this document is subject to change without notice. SmartAVI makes no war- ranty of any kind with regard to this material, including but not limited to, implied warranties of merchant- ability and fitness for particular purpose. SmartAVI will not be liable for errors contained herein or for inci- dental or consequential damages in connection with the furnishing, performance or use of this material.
