DEHUMIDIFIER
MODEL
MJ-EV240HP-H
INSTRUCTION MANUAL
Features
Compact and powerful
Eco Auto, energy saving
Air purifying function with
PM2.5 filter
This appliance is designed for use in Hong Kong and
Macau only and please do not use in any other countries.
Table of Contents
ECO AUTO/EASY/HIGH/LOW/MILDEW GUARD
OFF TIMER/ON TIMER/
English
2
3
5
5
6
7
7
8
9
9
10
12
15
15
15
16
17
18
19
20
21
21
22
24
24
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric MJ-EV240HP-H
Summary of Contents for Mitsubishi Electric MJ-EV240HP-H
-
Page 1: Table Of Contents
DEHUMIDIFIER MODEL MJ-EV240HP-H INSTRUCTION MANUAL English Table of Contents Features Recommended Ways of Compact and powerful Using the Unit Eco Auto, energy saving Precautions Air purifying function with Warning Tips on Dehumidification PM2.5 filter Features of This Dehumidifier Names and Functions of Parts... -
Page 2: Recommended Ways Of Using The Unit
Recommended Ways of Using the Unit When you want to dry laundry When you want to perform automatic operation INTELLIGENT LAUNDRY When you want to perform continuous operation Tips on Drying Laundry HIGH 12-13 When you want to dehumidify 12-13 When you want to set the humidity ECO AUTO When you want to perform automatic operation... -
Page 3: Precautions
The plastic parts may melt and cause fire. Continuing to operate the unit may result in fire or electric shock. Do not put your fingers Contact your dealer or Mitsubishi Electric Service or any long object, into Centre for consultation. the air intake/outlet. Do... - Page 4 CAUTION Do not cover an air outlet or Do not use the unit for special air intake with laundry, cloth, purposes, such as curtain, etc. preservation of food, art or scientific works. This results in poor ventilation and may cause heat generation/fire. This may negatively affect the quality of the items stored.
-
Page 5: Warning
Precautions (Cont.) Tips on Dehumidification CAUTION Grasp the plug and remove Drain the water tank before use. from the power socket. When removing the plug from Close the door and windows during the power socket, do not pull on it diagonally or by the cord as this operation. -
Page 6: Features Of This Dehumidifier
Features of This Dehumidifier Room temperature may rise Inverter The inverter is a device that controls the rotational speed of the 2–6°C during operation. compressor motor. When an operation starts immediately or in The dehumidifier does not have a cooler function. Due other situations, strong dehumidification is performed at a high motor speed. -
Page 7: Names And Functions Of Parts
It is impossible to remove the back panel Air Outlet because the four places shown are tightened with four special screws. Control Panel If the unit has any malfunctions, contact the Mitsubishi Electric Service Centre. Tank Lid P9·19 Tank Guard P9·19 Water Tank... -
Page 8: Control Panel/Inverter Indicator/Lcd Display
Names and Functions of Parts (Cont.) Control Panel DRYING INSIDE Switch DRYING INSIDE Lamp FULL Lamp Inverter Indicator LCD Display Lights when the tank is full of water. ON/OFF TIMER HUMIDITY LAUNDRY Switch SELECTION Switch Switch AIR PURIFIER Switch SWING LOUVRE MODE Switch POWER Switch AIR PURIFIER Lamp... -
Page 9: Before Using Your Dehumidifier
Before Using Your Dehumidifier Setting the PM2.5 filter Inserting the water tank correctly The PM2.5 filter is supplied with the unit at time of purchase. Please install it before using the unit. Remove the PM2.5 filter from the Tank lid polyethylene bag. -
Page 10: Drying Laundry
Drying Laundry When in the operation of INTELLIGENT LAUNDRY, the unit stops automatically when the laundry is dry. After the unit stops or the power plug is Blip inserted, the compressor will not be activated Press (for compressor protection). The dehumidifier will begin to work in 3 minutes after pressing the POWER switch. - Page 11 Tips on Drying Laundry Make full use of the laundry drying operation to shorten the laundry drying time. How to Hang Clothes Pull to remove any wrinkles on the laundry. Properly space the laundry for better ventilation (approximately 5 cm between the laundry). Hang out the laundry which is difficult to dry to the place with good ventilation.
-
Page 12: Dehumidifying
Dehumidifying The operation mode can be selected accordingly to the situation. Blip The operation mode is displayed. Press to begin operation. Inverter indicator lights. Louvre opens, and blows air. Select the operation mode. To select the dehumidifying mode and operate Press The operation mode switches each time the button is pressed. - Page 13 ECO AUTO In order to maintain the humidity level, the unit <To confirm the humidity setting> operates intermittently after automatic switching of air flow rate. After displaying the current humidity setting is When the current humidity is lower than the set displayed.
- Page 14 Dehumidifying (Cont.) MILDEW GUARD In this mode, the unit can dehumidify the bathroom to remove residual moisture and water drops, thus suppressing the mildew growth as a means of mildew prevention. To install the unit Install the unit in the changing room (entrance to the bathroom) (Do not install inside the bathroom) Adjust the unit so that...
-
Page 15: Cleaning The Air (Air Purifier)
The lifetime of the PM2.5 filter is one year. (It varies depending on the usage conditions) (Example) Remove the pre-filter and replace the PM2.5 filter. Removing the filter P9 PM2.5 filter for replacement Type: MJPR-EHPFT-HK Contact the Mitsubishi Electric Service Centre for purchase. -
Page 16: Using Louvre
Using Louvre The louvre can be made to swing. Select from the 4 possible settings to suit the purpose. Louvre stopped Blip Blip Each time Rear Blip the switch is pressed, the swing Blip Upward direction Blip Press changes. Automatic louvre starts The monitor displays louvre direction Blip Wide... -
Page 17: Using Timer
Using Timer OFF TIMER operation ON TIMER operation The OFF TIMER can be set between 1 to 12 hours. Set The ON TIMER can be set between 1 to 12 hours. the timer when the power is switched on. Set the timer when the POWER is off. 1 . -
Page 18: Drying Inside Operation
Drying Inside Operation The inside of the unit can be dried to suppress mildew growth on the cooler. The DRYING INSIDE operation is recommended after each use of the unit (approx. 1 hour). However, when continuous operation is being performed by continuous drainage (setting hose), there is no need to perform the DRYING INSIDE operation. -
Page 19: Draining
Draining When the tank is full (approximately 5.5 L), the unit automatically stops and the FULL lamp lights. Please empty the tank. When the water tank becomes full, the FULL lamp lights. After pouring out the water, replace the water tank, FULL lamp lights. -
Page 20: Continuous Drainage
Continuous Drainage If a drain is available, the unit can continuously drain water by attaching a commercially available hose (with an internal diameter of 15 mm) to the drain. As the unit does not stop due to the water tank being full, it can be operated for a long period of time without the need to empty the water tank. -
Page 21: Maintenance
Maintenance Storage Do not use detergents, cleaning agents for heat After switching the unit POWER off, leave for one day exchange equipment, decontaminative powders, until any residual water inside is removed. Then carry chemically treated cloth, gasoline, volatile oil, thinners, out the following steps. -
Page 22: Troubleshooting
Troubleshooting For the symptoms listed below, refer to the remedies listed right. Symptom Cause/Remedy The unit blows out warm air because dehumidified air passes through The unit blows warm air. the re-heater. (There is no cooler function.) This is not a malfunction. Check to see if the temperature/humidity is low. - Page 23 If the symptoms persist even after following the prescribed remedies, or the error message does not disappear, unplug the power cord, and contact the Mitsubishi Electric Service Centre. If the power cord is damaged, it must be replaced by the manufacturer, its services agent or similar qualified persons in order to avoid a hazard.
-
Page 24: Specifications
Unit Do not disassemble. Dispose according to the garbage regulations in your district. Sole Agent in Hong Kong Mitsubishi Electric (Hong Kong) Ltd. Please complete the following form for your future reference. Place of Purchase: Telephone Number: Authorised Service Centre:...
