DEHUMIDIFIER
MODEL
MJ-E26CX-H

INSTRUCTION MANUAL

Features
INTELLIGENT LAUNDRY
DEO-DRY
BATHROOM MILDEW GUARD
DRYING INSIDE
In order to ensure correct usage, please read this
instruction manual carefully and retain it for future
reference.
Before accepting the Warranty at the time of purchase,
please make sure that the date of purchase, place of
purchase and other items are correctly fi lled in the form.
Keep the Instruction Manual and Warranty in a safe
place.

Table of Contents

Before using the unit
Features of this dehumidifi er ···················· 3
Precautions ················································· 4
Warning ······················································· 6
Names and Functions of Parts ················· 6
Before using your dehumidifi er ·············· 10
Operating
Tips on Drying Laundry ··························· 11
operation ··················································· 12
EASY DEHUMIDIFYING (AUTO)
operation ··················································· 13
AUTO ····· 13
Using Child Lock ······································ 14
(Bathroom Mildew Guard) ·························· 15
Using Louvre ············································ 16
Using Timer ·············································· 17
(Clothes Deodorant) ··································· 18
Drying Inside Operation··························· 19
Draining ····················································· 20
Continuous Drainage ······························· 21

Troubleshooting

Maintenance ············································· 22
Replacement Parts ··································· 23
Storage and Disposal······························· 23
Troubleshooting ······································· 24
Specifi cations ··········································· 26
English
page

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi Electric MJ-E26CX-H

Summary of Contents for Mitsubishi Electric MJ-E26CX-H

  • Page 1: Table Of Contents

    DEHUMIDIFIER MODEL MJ-E26CX-H INSTRUCTION MANUAL English Table of Contents page Before using the unit Features INTELLIGENT LAUNDRY Recommended Ways of Using the Unit ··· 2 DEO-DRY Features of this dehumidifi er ···················· 3 BATHROOM MILDEW GUARD Precautions ················································· 4 DRYING INSIDE Warning ·······················································...

  • Page 2: Recommended Ways Of Using The Unit

    Recommended Ways of Using the Unit When you want to dry laundry When you want to perform automatic operation INTELLIGENT LAUNDRY When you want to perform continuous operation Tips on Drying Laundry HIGH When you want to dehumidify When you want to perform automatic operation EASY DEHUMIDIFYING When you want to perform continuous operation HIGH...

  • Page 3: Features Of This Dehumidifi Er

    Features of this dehumidifi er Room temperature may rise The unit can operate in a room 2-4°C during operation. temperature range of 1-35°C. However, if the room temperature exceeds 35°C, the unit may The dehumidifi er does not have a cooler function. Due to operate in blower mode or increase the airfl...

  • Page 4: Precautions

    (Keep pets from biting the cord.) This may result in fi re and/or electric shock. Refer servicing to your dealer or Mitsubishi Electric Service Centre. The cord may be damaged resulting in fi re, Exclusively use 220 to 240 V AC electric shock or heat generation.
  • Page 5 CAUTION Do not cover an air outlet or Do not use the unit for special air intake with laundry, cloth, purposes, such as curtain, etc. preservation of food, art or scientifi c works. This results in poor ventilation and may cause heat generation/fi re. This may negatively affect the quality of the items stored.

  • Page 6: Warning

    Precautions (Cont.) Precautions (Cont.) Names and Func CAUTION Front Grasp the plug and remove from the power socket. When removing the plug from the power socket, do not pull on it diagonally or by the cord as this may cause the projections/wiring to be damaged resulting in a short circuit, electric shock or fi re.
  • Page 7 ctions of Parts Back Handle Louvre Rear Air Intake Main Air Outlet Silver ion fi lter P22~23 Control panel Pre-fi lter Downward louvre Downward Air Outlet Tank lid P10·20 Tank Guard P10·20 Storage Hook Cord Tie Floating Element Remove during operation Water Tank P10·20 Power plug...

  • Page 8: Names And Functions Of Parts

    Names and Functions of Parts (cont.) Control Panel SWING LOUVRE Switch DRYING INSIDE lamp Sets the swing louvre direction or Flashes during locks it into position. the drying inside operation. Lights when the drying inside operation is Tank FULL lamp waiting to begin.

  • Page 9: Lcd Display

    LCD Display All of the indicators on the LCD display are shown for explanation purposes. Operating Mode Indicator Indicates the selected operating mode. P13~15 Swing Monitor Timer Display Humidity Indicator Indicates the swing Indicates the time of Indicates the approximate direction.

  • Page 10: Before Using Your Dehumidifi Er

    Before using your dehumidifi er Set the silver ion fi lter Inserting the water tank correctly The silver ion fi lter is supplied with the unit at time of purchase. Please fi t before using the unit. Check the tank and tank guard, Remove the silver ion fi lter and insert the tank all the way in.

  • Page 11: Tips On Drying Laundry

    Tips on Drying Laundry To dry laundry quickly and neatly How to Hang Clothes Fully extend the clothes to remove any wrinkles. Leave space between clothes to allow air to easily pass through them (Guideline for spacing: Approximately 5 cm) Hang any diffi cult to dry items in positions where wind can easily come into contact with them.

  • Page 12: When You Want To Perform Automatic

    When you want to perform automatic The unit performs operation automatically while monitoring the temperature and humidity in the room, thus alleviating the need for advanced operation settings. Use EASY DEHUMIDIFYING when you want to dehumidify the room and INTELLIGENT LAUNDRY when you want to dry laundry.

  • Page 13: Operation

    When you want to operation perform manual operation You can select from fi ve operating modes: HIGH, LOW, BATHROOM MILDEW GUARD, LOW TEMP, and AUTO. (HIGH, LOW, and LOW TEMP: P14 , BATHROOM MILDEW GUARD: P15 ) AUTO When you want to set the humidity and perform dehumidifying Press Press to select the operating mode...

  • Page 14: High · Low · Low Temp

    When you want to perform Using Child Lock manual operation (cont.) You can lock the switches. You can select from fi ve operating modes: HIGH, LOW, Use this function when you want to stop children BATHROOM MILDEW GUARD, LOW TEMP, and AUTO. operating the unit.

  • Page 15: Reducing Growth Of Mildew In Bathroom

    Reducing Growth of Mildew in Bathroom (Bathroom Mildew Guard) This operation is for reducing the growth of mildew by drying the inside of a bathroom to remove any humidity and droplets that remain inside after, for example, you take a bath. This operation can also be used as a measure for tackling mildew in rooms. Installing the Dehumidifi er Install the dehumidifi er in the dressing room...

  • Page 16: Using Louvre

    Using Louvre The louvre can be made to swing. Select from the 5 possible settings to suit the purpose. Changes Stop swing with each press the swing direction. Wide During operation, Press to select the Upward operating mode Downward The swing monitor indicates the range in which the louvre swings.

  • Page 17: Using Timer

    Using Timer When using the timer, drain the water from the tank before beginning operation. When the tank becomes full of water, dehumidifying cannot be performed because operation stops. OFF Timer Operation ON Timer Operation You can set an operating time between 1 to 9 hours. You can set an operating start time between 1 to 9 Set the time when you turn the power ON.

  • Page 18: Removing Odor From Clothes

    Removing Odor from Clothes (Clothes Deodorant) The unit operates for approximately 1 hour to remove odor from clothes. <Use for odor from the following> Use this operation when you want to remove odor from clothes that are not Cigarettes and grilled meat frequently washed, such as suits and sweaters.

  • Page 19: Drying Inside Operation

    Drying Inside Operation The inside of the unit can be dried to suppress mildew growth on the cooler. On days the dehumidifi er is used, internal drying is recommended. Automatic operation Manual operation To activate internal cleaning after every use. Press the to activate internal cleaning while the unit is OFF.

  • Page 20: Draining

    Draining The unit automatically shuts down and lights the Tank full lamp when the tank is full. Empty the tank. When the tank becomes full, the FULL lamp lights. After removing the water and replacing the tank, the Tank full lamp will go off, and the unit will automatically return to operation mode.

  • Page 21: Continuous Drainage

    Continuous Drainage If a drain is available, the unit can continuously drain excess water by attaching a commercially available hose (internal diameter 15mm). The unit can be operated for extensive periods without the need to empty the water tank. Commercially available hose (I.D. 15mm) CAUTION Items to Long enough to reach the drain.

  • Page 22: Maintenance

    Maintenance Do not use detergents, cleaning agents for heat exchange equipment, abrasive powders, chemically treated dusters, gasoline, benzene, thinners or other solvents, as they can damage the unit or the water tank, which may result in leakage. Remove the power plug before you begin maintenance. Cleaning Once Every Three Months Water tank ·...

  • Page 23: Replacement Parts

    Replacement Parts Storage and Disposal Storage The silver ion fi lter is a consumable item. Replace this fi lter when it becomes time for replacement. After switching the unit off, leave for one day until any water inside has had time to settle. Then carry Replacing the silver ion fi...

  • Page 24: Troubleshooting

    Troubleshooting For the symptoms listed below, refer to the remedies listed right. Symptom Cause/Remedy The unit blows out warm air because dehumidifi ed air passes through The unit blows warm air the reheater (there is no cooler function). This is not a malfunction. Water does not collect in Check to see if the temperature/humidity is low.
  • Page 25 Symptom Cause/Remedy Check to see if the unit is on a slope or uneven surface. → Move to a sturdy even surface. The operating Check to see if the pre-fi lter is clogged. → noise is loud/ Clean according to the maintenance procedures. reverberates Operating the unit in small rooms or in tight spaces sometimes causes the sound to reverberate.

  • Page 26: Specifi Cations

    If the unit malfunctions, contact your Mitsubishi dealer. Sole Agent in Hong Kong Mitsubishi Electric Ryoden Air-Conditioning & Visual Information Systems (Hong Kong) Limited. Offi ce: Tel.: 2510 1505 Service Center: Tel.: 2427 8484 Fill in the following for your future reference.
