MITSUBISHI
MODEL
MJ-E16SX-A1
INSTRUCTION MANUAL
Features
GPowerful Dehumidifying
GWide-angle Swing Louvre
GFull Auto. Laundry
Protect our environment and enrich our lives by
saving energy
Table of Contents
dehumidifier...........................................2
¡Precautions............................................3
¡Warning ..................................................5
¡Names and functions of parts .............6
¡Things to be aware of...........................8
¡Before using your dehumidifier...........8
¡Turning the Unit ON and OFF ..............9
¡Switching operating modes ...............10
Full Auto - Laundry - Low - Mildew Guard -
¡Swing louvre function ........................12
¡Information display .............................13
High humidity warning - Defrosting indicator -
Low temperature indicator - Water full lamp
¡Using the Timer ...................................14
¡Using the Child lock ...........................16
¡Moving the unit ...................................16
¡Removing water from the tank ..........17
¡Continuous drainage ..........................18
¡Maintenance ........................................19
¡Replacing the Air purifying filter.............21
¡Storage.................................................21
¡Troubleshooting ..................................22
¡Specifications......................................24
¡In order to ensure correct usage, please read
this instruction manual carefully and retain it for
future reference.
¡Before accepting the Warranty at the time of
purchase, please make sure that the date of
purchase, place of purchase and other items
are correctly filled in the form.
Printed on recycled paper.
page
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric MJ-E16SX-A1
Summary of Contents for Mitsubishi Electric MJ-E16SX-A1
-
Page 1: Table Of Contents
MITSUBISHI MODEL MJ-E16SX-A1 INSTRUCTION MANUAL Table of Contents page Features GPowerful Dehumidifying ¡Getting the most out of your GWide-angle Swing Louvre dehumidifier...........2 ¡Precautions..........3 GFull Auto. Laundry ¡Warning ..........5 ¡Names and functions of parts .....6 ¡Things to be aware of......8 ¡Before using your dehumidifier...8 ¡Turning the Unit ON and OFF ....9... -
Page 2: Getting The Most Out Of Your
Getting the most out of your dehumidifier Combine operating mode and swing louvre function to get optimum results. Objective Recommended mode and louvre setting Page ¡ Selection When you don’t want to Laundry Drying ¡Selection hang the clothes laundry ¡ Louvre setting outside or it is raining... -
Page 3: Precautions
The plastic parts may melt causing Refer servicing to your dealer or speeds, and such actions may fire. Mitsubishi Electric Service Centre. result in injury or malfunctions. Wipe dust off the power Use 220-240V AC power sockets Should abnormal symptoms that can withstand more than 15A occur (a burning smell, etc.),... - Page 4 Precautions CAUTION Do not cover the side air Do not stand on, sit on or Do not put vases or any intakes or the air outlet lean against the unit. other objects filled with with cloth, curtain, etc. water on the unit. Water may leak into the unit adversely affecting electric insulation The unit may tip over causing...
-
Page 5: Warning
CAUTION Do not point air-flow from Install the unit in a location where Grasp the plug and remove the unit directly at the the floor is flat and stable. from the power socket. body . If the unit falls over, the water When removing the plug from the collected in the water tank may power socket, do not pull on it... -
Page 6: Names And Functions Of Parts
Names and Functions of Parts Front Control Panel Control panel Air purifying filter Already installed at time of purchase Air filter ¡Lamp Current mode lights Front panel ¡Selection button Switches modes Water tank • Tank lid • Floating element 6 operating mo Front door SELECTION The water tank may contain water residue at... -
Page 7: Power Button
¡Mode button ¡Swing louvre ¡Power lamp For switching from one operating Lights when unit is ON. button mode to another ¡Power button Sets swing louvre ¡Child lock direction or locks it into Use this to switch the To set the child lock, press the mode position unit OFF and ON. -
Page 8: Things To Be Aware Of
Things to be aware of How does the dehumidifier Room temperature may rise work? 2-4°C during operation If you pour cold water into a cup, the air around it becomes cold, causing water droplets to form The dehumidifier does not have a cooler function. Due on the surface of the cup. -
Page 9: Before Using Your Dehumidifier
Before using your Turning the Unit dehumidifier ON and OFF Inserting the water To turn ON tank correctly Tank lid Open the front door. Press Confirm that the lid is ¡Power lamp lights securely attached to ¡The mode is displayed. the water tank. -
Page 10: Switching Operating Modes
Switching operating modes You can choose between six operating modes. Reading the humidity display CURRENT indicates the current humidity. Current humidity range is between 30-80%. • Humidity levels below 30% are displayed as 30%. • Humidity levels above 80% Low, Mildew Guard, and Low Temp Full Auto &... -
Page 11: Low Temp - Auto
* The humidity level cannot be set in Low, Mildew Guard, and Low Temp modes. When you want to leave the dehumidifier on ¡Low The unit continually operates the dehumidifier regardless of current humidity. When you want to suppress mildew growth ¡Mildew Guard The unit lowers room humidity levels once a day (for approximately 2-4 hours), suppressing mildew growth. -
Page 12: Swing Louvre Function
Swing louvre function (how to read the Swing monitor) The louvre can be made to swing. Select from the 4 possible settings to suit the purpose. Press ¡Starts swing operation. Viewing the Swing Monitor ¡The swing monitor is This indicates the range of louvre swing. displayed. -
Page 13: Information Display
Information Display Displays room and dehumidifier conditions. LCD Panel Indicator lamp High humidity warning Tank full lamp The unit automatically shuts down and indicator flashes when the indicates with the lamp and sound that humidity in the room exceeds 75%. the water tank is full. -
Page 14: Using The Timer
Using the Timer OFF timer operation The OFF timer can be set for 1 to 9 hours. Set the timer when the power is switched on. To set To cancel Switch the power on. <When you want to turn the unit off>... - Page 15 ON timer operation The ON timer can be set for 1 to 9 hours. Set the timer when the power is switched off. 4 1, 5 To set The following is an example of a display indicating AUTO dehumidifying (set to 60%), Switch the power off.
-
Page 16: Using The Child Lock
Using the Carrying the Child Lock Unit To Lock Pull the handle out, and grasp with a firm grip Press for 3 or more seconds. ¡ The child lock indicator The child lock is switched off when the power cord is unplugged. When the child lock is activated the unit cannot be switched off or on. -
Page 17: Removing Water From The Tank
Removing Water from the Tank The unit automatically shuts down and lights the Tank full lamp when the tank (approximately 4L) is full. Empty the tank. Remove the water tank. Remove the tank lid, and empty. water tank Open the front door Floating element Do not remove or dismantle the float. -
Page 18: Continuous Drainage
Continuous Drainage If a drain is available, the unit can continuously drain excess water by attaching a commercially available hose (internal diameter 15mm). The unit can be operated for extensive periods without the need to empty the water tank. CAUTION Do not drain water continuously When draining water continuously or if there is a possibility that... -
Page 19: Maintenance
Maintenance Once every two weeks Air filter Debris clogging the air filter reduces the effectiveness of the dehumidifier. Clean once every 2 weeks. Remove front panel and air Clean the air filter Run a vacuum filter cleaner lightly over the air filter Air filter Front surface to... -
Page 20: Water Tank
Maintenance Do not use detergents, cleaning agents for heat exchange equipment, abrasive powders, chemically treated dusters, gasoline, benzene, thinners or other solvents, as they can damage the unit or the water tank, which may result in leakage. Cleaning Water tank Main unit Wipe with a soft... -
Page 21: Replacing The Air Purifying Filter
Replacing the Air Purifying Filter Storage After switching the unit off, leave for about one day The air purifying filter is disposable. until any water inside has had time to settle. Then carry Make sure to replace the filter when it becomes dirty. out the following steps. -
Page 22: Troubleshooting
Troubleshooting ¡ For the symptoms listed below, refer to the remedies listed right. Symptom Cause/Remedy ¡ Dehumidified air passes through heating coils causing it to The unit blows warm air warm (this unit is not a cooler). This is not a malfunction. ¡... - Page 23 Symptom Cause/Remedy ¡ Check to see if the unit is on a slope or uneven surface. ➝ Move to a sturdy even surface. The operating ¡ Check to see if the air filter is clogged. noise is → Clean according to the maintenance procedures loud/reverberates ¡...
-
Page 24: Specifications
Specifications Model MJ-E16SX-A1 Power supply Single phase 230-240V 50Hz Dehumidifying capacity 16 L/day Power consumption 275W Water tank capacity stops automatically at approx. 4.0L Weight 11.7kg Dimensions (h × w × d) 570mm × 384mm × 183mm ∞ The dehumidifying capacity is a value obtained when the dehumidifier is continuously run at a room temperature of 30°C and humidity of 80%.
