SETTING UP THE EVALUATION BOARD

INPUT CONFIGURATION

A 4-pin header (J1) on the middle left side of the board feeds the
audio signal into the board (see Figure 1). If the input audio signal
is differential (IN+ and IN−), three pins of J1 are used for IN+,
IN−, and signal ground. For a single-ended audio input, only two
pins of J1 are used. One is for the signal ground and the other is
for either IN+ or IN−. If IN+ is used, place a jumper between
Pin 3 and Pin 4 of J1, shorting IN− to ground. If IN− is used,
place the jumper between Pin 1 and Pin 2 of J1, connecting IN+
to ground.

OPERATION MODE CONFIGURATION

The 6-pin header, J2, is used to turn on/off the SSM2317 amp-
lifier and configure the ALC operation modes. Placing a jumper
across Pin 1 and Pin 2 of J2 shuts down the
a minimum current (about 20 nA) is drawn from the power supply
(when R3 is shorted). Removing the jumper puts the SSM2317 in
normal operation. Placing a jumper across Pin 3 and Pin 4 of J2
disables ALC mode, while removing the jumper activates ALC
mode. When ALC is disabled, the SSM2317 behaves like a tradi-
tional amplifier with a fixed 18 dB. Placing a jumper across Pin 5
and Pin 6 of J2 shorts across the ALC threshold resistor (on
board) and sets a maximum limiter level of 90% of V
ALC is activated).

OUTPUT CONFIGURATION

The output connector, J4, is located on the right side of the board
(see Figure 1). J4 drives a loudspeaker whose impedance should
be no less than 3 Ω.
Although the SSM2317 does not require any external LC output
filters due to a low noise modulation scheme, if the speaker length
is >10 cm, it is recommended to put a ferrite bead (L1 and L2) near
each output pin of the SSM2317 to reduce electromagnetic interfer-
ence (EMI), as shown in the schematic in Figure 3. Some users may
want to replace the ferrite beads with these inductors to evaluate
applications with specific EMI vs. audio performance constraints. As
an aid, a properly tuned ferrite bead-based EMI filter is assembled at
the output terminals of the device.
For optimal performance, as specified in the SSM2317 data sheet
(in particular, for THD and SNR), remove the entire EMI filter,
short across the ferrite bead terminals, and open the capacitor
terminals.

POWER SUPPLY CONFIGURATION

The evaluation board schematic is shown in Figure 3. The 2-pin
header, J3, must be used to power the board. Care must be taken
to connect the dc power with correct polarity and voltage. The
positive voltage terminal of J3 (VDD) is indicated with an arrow
in Figure 1.
