Ellisys SerialTek Gen5 POD EDSFF Assembly page 7

Gen5 POD EDSFF Edition Assembly Reference
Raise M3 Captive Screws till it resists and screw thread clears
the underside of PCBA, then slide the 4CM - 1CF E3 Device
PCBA into the connector on the DEVICE side of the POD Unit
and secure in position on the SFF-TA-1008 Spacer Base Plate
with M3 Captive Screws.
M3 Captive Screw
4CM - 1CF E3 Device PCBA
EDSFF Device Adaptor Base Tray
0004642 - R1.4
Page 7 of 9
POD Main Unit
SFF-TA-1008 Spacer Base Plate
SFF-TA-1008 (E3)
