Gen5 POD SSAS Edition Assembly Reference
Raise M3 Captive Screws till it resists and screw thread clears the
underside of PCBA, then slide the SSAS Host PCBA into the connector on
the HOST side of the POD Unit and secure in position on the
Host/Device Cable Adaptor Tray with M3 Captive Screws.
0004646 - R1.4
Page 5 of 5
POD Main Unit
SSAS Host PCBA
Host/Device Cable Adaptor Tray
M3 Captive Screw
