Gen5 POD SSAS Edition Assembly Reference
Raise M3 Captive Screws till it resists and screw thread clears the
underside of PCBA, then slide the SSAS Device PCBA into the
connector on the DEVICE side of the POD Unit and secure in position
on the Host/Device Cable Adaptor Tray with M3 Captive Screws.
M3 Captive Screw
SSAS Device PCBA
0004646 - R1.4
Page 3 of 5
POD Main Unit
Host/Device Cable Adaptor Tray
