Gen5 POD SSAS Edition Assembly Reference
Slide the Host/Device Cable Adaptor Tray into the slot on the HOST side on
the underside of the POD Main Unit at an angle of about 60 ~ .
Rotate the Cable Adaptor Tray so it is horizontal and tighten the M3 Captive
Panel Screws to the POD Main Unit, ensuring not to over tighten.
M3 Captive Panel Screw
0004646 - R1.4
Page 4 of 5
Host/Device Cable Adaptor Tray
POD Main Unit
