- Page 1 32-Bit Microcontroller TriBoard TC176X/TC116X/TC1782/ TC1387 Hardware: TriBoard-LQFP176 V2.1 Hardware Manual User’s Manual V 2.1 2009-06 M i c r o c o n t r o l l e r s...
- Page 2 Infineon Technologies components may be used in life-support devices or systems only with the express written approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the failure of that life-support device or system or to affect the safety or effectiveness of that device or system. Life support devices or systems are intended to be implanted in the human body or to support and/or maintain and sustain and/or protect human life.
- Page 3 32-Bit Microcontroller TriBoard TC176X/TC116X/TC1782/ TC1387 User’s Manual V 2.1 2009-06 M i c r o c o n t r o l l e r s...
- Page 4 Trademarks ® TriCore is a trademark of Infineon Technologies AG. We Listen to Your Comments Any information within this document that you feel is wrong, unclear or missing at all? Your feedback will help us to continuously improve the quality of this document.
-
Page 5: Table Of Contents
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Table of Contents Introduction ..........1-1 TriBoard Features . - Page 6 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual OCDS connector pinout ........7-5 DAP connector pinout (only with TC1767, TC1782, TC1387) .
- Page 7 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual List of Figures Figure 2-1 TriBoard Block Schematic ....... . . 2-3 Figure 2-2 TriBoard LQFP176 V2.1 Placement .
- Page 8 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual User’s Manual V 2.1, 2009-06...
- Page 9 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual List of Tables Table 4-1 User Startup Modes for TC1767, TC1782 and TC1387 ..4-1 Table 4-2 HW Boot Configuration for all other TC176X / TC116X ... 4-2 Table 4-3 General optional resistors .
- Page 10 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual User’s Manual V 2.1, 2009-06...
- Page 11 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual User’s Manual V 2.1, 2009-06...
-
Page 12: Introduction
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Introduction Introduction We congratulate you on your purchase of the TriCore Evaluation Board. This kit is a versatile tool, providing quick access to the capabilities of TriCore's powerful architecture. Applications can be developed easily. The Evaluation Board is equipped with a variety of memories and peripherals for connection to the environment. - Page 13 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Introduction User’s Manual V 2.1, 2009-06...
-
Page 14: Triboard Features
Hardware Manual TriBoard Features TriBoard Features The TriBoard TC176X/TC116X/TC1782/TC1387 is soldered with a device of the TC176X or TC116X or TC1782 or TC1387. This devices fits into all members of this product family so that there are no special TriBoards necessary. - Page 15 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Features – USB to UART bridge FT2232D (FTDI) – SPI eeprom (Atmel) – 8 general purpose LEDs – Reset switch – 8-pin Dip switch Zero Ohm Bridges Zero Ohm resistors give the flexibility to configure the systems functionality User’s Manual...
-
Page 16: Block Diagram
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Features Block Diagram XTAL CAN0 TxCAN0 TC176X / RxCAN0 TC116X / Transceiver CAN1 TxCAN1 RxCAN1 TC1782 / TC1387 OCDS1 B-TYPE miniWiggler TriCore TXD0 RXD0 FlexRay only with TC1767, Safety Device TC1782 and TC1387 SAK-CIC61508 optional if not with TC1387... -
Page 17: Placement
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Features Placement P401 X704 X701 P5.0 P5.1 P5.2 P5.3 P5.4 P5.5 P5.6 P5.7 BOOTCONFIG X403 ERAY-A X402 OCDS1 XT201 CLOCK SEND X401 U201 SENC U202 JP202 ERAY-B SAK-CIC61508 RESET SENB JP201 JP203 +3V3 TC176X/TC116X/ +VDD... -
Page 18: Triboard Information
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Information TriBoard Information Power Supply The Board has to be connected to a +5,5V to +50V (+40V) DC power supply. The TriBoard generates internally +3.3V, +VDD and +5V. The power consumption is not specified yet but a supply with 6V and 500mA should be sufficient. The pinout for the... -
Page 19: Usb Connector
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Information The crystal oscillator and the oscillator circuit use the socket XT301. It's possible to apply a 14pol DIP oscillator package or an 8pol DIP oscillator package. OSCILLATOR DIP14 OSCILLATOR DIP8 External Clock Input Figure 3-1... -
Page 20: Flexray / Iflex (Optional If Not With Tc1767, Tc1782 Or Tc1387)
If the board comes without FlexRay (e.g. with TC1766) then you can add the FlexRay option by assembling the following parts: • U301 with SAK-CIC310 (Infineon) • U302 and U303 with AS8221 (AMS) or TJA1080 (NXP) (if with TJA1080 then... -
Page 21: Safety Option With Sak-Cic61508 (Optional If Not With Tc1387)
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Information Safety option with SAK-CIC61508 (optional if not with TC1387) The safety device is only assembled if the board is with TC1387 or with the safety option. The SAK-CIC61508 is connected to the SSC0 of the microcontroller and use the line SLSO01 (P3.6) as chip select. -
Page 22: Dap
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Information If the ACTIV LED is on, then stop the active DAS Server JTAG over USB Chip and/or remove the USB connection to the PC. 3.11.2 If the board comes with a TC1767, TC1782 or TC1387 then the DAP connector (X402) is available. - Page 23 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Information User’s Manual V 2.1, 2009-06...
-
Page 24: Triboard Configuration
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Configuration TriBoard Configuration HW Boot Configuration TC1767, TC1782 and TC1387 HIGH Figure 4-1 HW Configuration TC1767, TC1782, TC1387 DIP-Switch The picture above shows the definition of the boot HW configuration switch. The meaning of the switches will be described in the following table (Table 4-1). -
Page 25: Hw Boot Configuration All Other Tc176X / Tc116X
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Configuration Table 4-1 User Startup Modes for TC1767, TC1782 and TC1387 Note: The shadowed line indicates the default setting. Note: ’x’ represents the don’t care state. Note: 1 to 8 are the Dip Switch numbers HWCFG[7...0] Type of Boot TC1767, TC1782 and TC1387... - Page 26 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Configuration Table 4-2 HW Boot Configuration for all other TC176X / TC116X Note: The shadowed line indicates the default setting. Note: ’x’ represents the don’t care state. Note: 1 to 8 are the Dip Switch number P4[3...0]...
-
Page 27: Assembly Options
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Configuration Assembly Options Table 4-3 General optional resistors Component Description R205 XTAL Rserial (default: assembled) R206 XTAL Rparallel (default: not assembled) R423 Connect /BRKOUT with MiniWiggler (default: not assembled) R424 Connect /BRKOUT with OCDS1 connector (default: not assembled) -
Page 28: Figure 4-3 Location Of General Optional Resistors On Top Side
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Configuration Note: All resistors are red marked in the following figures CB406 R407 P401 R402 R403 X704 X701 U402 R404 R406 CB401 L401 R405 C401 D403 D402 X403 R401 R518 X401 R434 R213 R515 R516 R517... -
Page 29: Table 4-4 Resistors For Peripherals
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Configuration Table 4-4 Resistors for peripherals Component Description R333 Connect P3.12 with RXD of CAN0 transceiver (default: assembled) R339 Connect P3.14 with RXD of CAN1 transceiver (default: assembled) R353 Connect P3.5 (SLSO00) with /CS of Eeprom (default: assembled) R345 Connect P2.3 (MLI0) with IFlex (default: assembled) -
Page 30: Figure 4-5 Location Of Peripheral Resistors On Top Side
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Configuration Note: All resistors are red marked in the following figures CB406 R407 P401 R402 R403 X704 X701 U402 R404 R406 CB401 L401 R405 C401 D403 D402 X403 R401 R518 X401 R434 R213 R515 R516 R517... -
Page 31: Figure 4-7 Location Of Resistors For Safety Device On Bottom Side
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Configuration Table 4-5 Resistors for safety device Component Description R247 Connect potentiometer to sensor input C (default: assembled) R251 Connect potentiometer to sensor input D (default: assembled) R239/R240 Voltage divider to adapt VDDP to VAREF of safety device (default:... -
Page 32: Triboard Software
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Software TriBoard Software Requirements To install the software from your TriBoard CD you need a PC with Windows95/98/ME, Windows 2000, Windows XP or Windows Vista. Software Overview The CD does not contain any tool. For the availablity for Demo Versions of the different Tools, please contact the toolvendor directly (e.g. - Page 33 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual TriBoard Software User’s Manual V 2.1, 2009-06...
-
Page 34: Signal Description
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Signal Description Signal Description For more information about the signals please see the user manuals from TC176X/TC116X/TC1782/TC1387 and/or the schematics of the board. Table 6-1 Power Signals Short Name Description VCC_IN Supply Input (5,5V...50V(40V)) Input voltage of power supply device... -
Page 35: Table 6-3 Interrupt Signals
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Signal Description Table 6-3 Interrupt Signals Short Name Description /NMI (ESR1) Non Maskable Interrupt /RESET_CIC Reset safety device Table 6-4 Clock Signals Short Name Description XTAL1 Crystal Oscillator Input XTAL2 Crystal Oscillator Output XTAL1_CIC Crystal Oscillator Input safety device... - Page 36 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Signal Description Table 6-6 Peripheral Signals P3.2 Clock Line SSC0 P3.3 Master Receive / Slave Transmit SSC0 P3.4 Master Transmit / Slave Receive SSC0 P3.5 Slave Select Output 0 (SSC0) P3.13 CAN Transmitter Output 0 P3.12 CAN Receiver Input 0 P3.15...
-
Page 37: Table 6-7 Safety Device Signals
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Signal Description Table 6-6 Peripheral Signals P6.1 / FCLP0A MSC0 differential driver clock output positive A P6.0 / FCLN0 MSC0 differential driver clock output negative P6.3 / SOP0A MSC0 differential driver serial data output positive A P6.2 / SON0... -
Page 38: Connector Pin Assignment
Plug: FTSH-140-02-L-DV-ES-A Socket: FLE-140-01-G-DV-A Alternative there can be used the Board to Board System from Robinson Nugent: http://www.robinsonnugent.com Plug: P50L-80P-AS-TGF Socket: P50L-80S-AS-TGF Note: All connectors are pincompatible with the previous versions of TriBoard TC176X. User’s Manual V 2.1, 2009-06... -
Page 39: Tc176X/Tc116X Connector / Top View
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Connector Pin Assignment TC176X/TC116X Connector / Top View BUS EXPANSION (X801,X901) PERIPHERALS (X802,X902) VCC_IN VCC_IN VCC_IN VCC_IN 9 10 9 10 11 12 11 12 13 14 13 14 15 16 /ESR1 15 16 /ESR0 17 18... -
Page 40: Figure 7-2 Connector For Tc176X/Tc116X/Tc1782/Tc1387 - Pinout
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Connector Pin Assignment ADC (X803, X903) GPTA / MLI (X804,X904) VSSM VSSM VSSM VSSM AN16 GPTA0 / P0.0 GPTA32 / P2.0 AN17 GPTA1 / P0.1 GPTA33 / P2.1 9 10 AN18 GPTA2 / P0.2 9 10 GPTA34 / P2.2... -
Page 41: Power Connector Pinout
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Connector Pin Assignment Power connector pinout +5,5V...50V(40V) Figure 7-3 Power connector pinout USB connector pinout 2 (D-) 1 (Vbus) 3 (D+) 4 (GND) Figure 7-4 USB connector Pinout Flexray Pinout Figure 7-5 Flexray Pinout (SUBD-9 Plug) User’s Manual... -
Page 42: Can Connector Pinout
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Connector Pin Assignment CAN connector pinout Figure 7-6 CAN connector pinout (IDC10) OCDS connector pinout Figure 7-7 OCDS connector pinout (IDC16) DAP connector pinout (only with TC1767, TC1782, TC1387) Figure 7-8 DAP connector pinout (FTSH10) - only with TC1767, TC1782, TC1387 User’s Manual... - Page 43 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Connector Pin Assignment User’s Manual V 2.1, 2009-06...
-
Page 44: Schematic And Layout
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Schematic and Layout Schematic and Layout Schematic 8.1.1 New and changes on schematic version V2.1 to TriBoard TC176X/TC116X/TC1782/TC1387 V2.0 • add other power regulator for +1,3V core voltage on TC1782 (other devices not affected User’s Manual... -
Page 45: Figure 8-1 Schematic - Project
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Schematic and Layout Figure 8-1 Schematic - Project User’s Manual V 2.1, 2009-06... -
Page 46: Figure 8-2 Schematic - Config, Clock And Cic61508
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Schematic and Layout Figure 8-2 Schematic - Config, Clock and CIC61508 User’s Manual V 2.1, 2009-06... -
Page 47: Figure 8-3 Schematic - Iflex, Can And Eeprom
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Schematic and Layout Figure 8-3 Schematic - IFlex, CAN and Eeprom User’s Manual V 2.1, 2009-06... -
Page 48: Figure 8-4 Schematic - Miniwiggler, Dap And Etk
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Schematic and Layout Figure 8-4 Schematic - MiniWiggler, DAP and ETK User’s Manual V 2.1, 2009-06... -
Page 49: Figure 8-5 Schematic - Gpta, Msc, Mli And Adc
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Schematic and Layout Figure 8-5 Schematic - GPTA, MSC, MLI and ADC User’s Manual V 2.1, 2009-06... -
Page 50: Figure 8-6 Schematic - Power Supply
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Schematic and Layout Figure 8-6 Schematic - Power Supply User’s Manual V 2.1, 2009-06... -
Page 51: Figure 8-7 Schematic - Connectors (Plug)
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Schematic and Layout Figure 8-7 Schematic - Connectors (Plug) User’s Manual V 2.1, 2009-06... -
Page 52: Figure 8-8 Schematic - Connectors (Socket)
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Schematic and Layout Figure 8-8 Schematic - Connectors (Socket) User’s Manual V 2.1, 2009-06... -
Page 53: Layout
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Schematic and Layout Layout Figure 8-9 Component Plot Top Layer User’s Manual 8-10 V 2.1, 2009-06... -
Page 54: Figure 8-10 Component Plot Bottom Layer
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Schematic and Layout Figure 8-10 Component Plot Bottom Layer User’s Manual 8-11 V 2.1, 2009-06... -
Page 55: Layout With Dimensioning
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Schematic and Layout Layout with Dimensioning The following dimensions should be used for development of extension boards. Note: these are the pictures from the TriBoard TC10GP. Connectors X801...X804 are on the same place. Figure 8-11 Dimensioning (mil) User’s Manual... -
Page 56: Figure 8-12 Dimensioning (Mm)
TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Schematic and Layout Figure 8-12 Dimensioning (mm) User’s Manual 8-13 V 2.1, 2009-06... - Page 57 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual Keyword Index Numerics P4 4-2 Interrupt Signals 6-2 P0 4-2 Layout 8-10 ACTIV LED 3-2 LEDs 3-1 Assembly Options 4-4 Location of general optional resistors on Bottom Side 4-5 Location of general optional resistors on CAN connector pinout 7-5...
- Page 58 TriBoard TC176X/TC116X/TC1782/TC1387 Hardware Manual RUN LED 3-2 Safety device Signals 6-4 Safety option 3-4 Samtec 7-1 Schematic 8-1 Schematic and Layout 8-1 Serial Connection to PC 3-2 Serial EEPROM 3-3 Serial Eeprom 3-3 Signal Description 6-1 Software 5-1 status LED 3-4 Supply 3-1 Toggle LED’s 3-4...
- Page 59 . i n f i n e o n . c o m Published by Infineon Technologies AG...
