- Page 1 SUBWING 700 SUBWING 700 USER’S AND INSTALLER’S MANUAL V2.1 REV. 08/2022...
- Page 2 00. CONTENT 01. SAFETY INSTRUCTIONS INDEX ATTENTION: 01. SAFETY INSTRUCTIONS This product is certified in accordance with European 02. AUTOMATION Community (EC) safety standards. CONNECTION SCHEME This product complies with Directive 2011/65/EU of the INSTALLATION MAP European Parliament and of the Council, of 8 June 2011, on TECHNICAL SPECIFICATIONS the restriction of the use of certain hazardous substances DIMENSIONS...
- Page 3 01. SAFETY INSTRUCTIONS GENERAL WARNINGS the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. WARNINGS FOR TECHNICIANS very important. Read all instructions carefully before beginning the installation/usage procedures and keep this manual in a safe place •...
- Page 4 01. SAFETY INSTRUCTIONS • to the release mechanism. use or maintenance! • Disconnect means, such as a switch or circuit breaker on the electrical • Safety norms are not followed in the installation, use and panel, must be provided on the product’s fixed power supply leads in maintenance of the product.
- Page 5 02. AUTOMATION 02. AUTOMATION CONNECTION SCHEME TECHNICAL SPECIFICATIONS 230V • Max. weight of leaf 500Kg • Max. width of leaf 2,50m • Motors power supply 24V DC 230V AC 2x1,5mm2 (24V DC) • Motor power 280W 4x1,5mm2 (230V DC) • Rotational speed 1800 RPM 1400 RPM 2x0,75mm2...
- Page 6 03. INSTALLATION 03. INSTALLATION GATE LEAF OPENING ANGLE BOX INSTALLATION Establish the required opening angle. POSITION PILLAR Create a hole (taking into account 1 • the dimensions indicated in the 375mm image) to contain the motor support box (C1). 320mm INSIDE VIEW 90°...
- Page 7 03. INSTALLATION 03. INSTALLATION ASSEMBLING THE MOTOR AND LEVERS MOUNTING THE MOTOR LEVER TO THE GATE 1 • Place the motor in the box and secure it with the screws provided. Place and fix the cover with the screws provided. BALL Insert the ball on the box stud and apply the 2 •...
- Page 8 03. INSTALLATION 04. TROUBLESHOOTING EMERGENCY RELEASE FINAL CONSUMERS AND SPECIALIZED INSTALLERS INSTRUCTIONS Place the key (C) supplied, in the hole Problem Probable cause Solution (V), which is located in the lever L1 and turn it. • There is no 230V power •...
