Safety Notice
The manufacturer is discharged from liability when damage
is caused by improper use or installation.
If any luminaire and/or accessory is subsequently modi-
fied, the persons responsible for the modification shall be
considered as manufacturer.
Product Information / Surge Protection
As an option, this luminaire can also be fitted with a surge
protector of Type 2-3 (at the time of order). The technical
data can be found directly on the installed device. If the
surge protector has been triggered by an adverse event,
the luminaire is automatically disconnected from the
mains. In that case, the LED on the surge protector no
longer lights up.
For comprehensive protection of the luminaire against
lightning and electrical surges, primary (Type 1) and
secondary (Type 2) surge arrestors must be installed into
WE-EF LIGHTING USA
Tel +1 724 742 0030
info.usa@we-ef.com
we-ef.com
the power supply. We recommend a combination arrestor
(Type 1+2+3), which is installed in the control cabinet.
The technical planner/installer is responsible for the pro-
per selection, sizing and installation of the surge protection
modules that must be provided on site. Please note the
various protection levels for Class I and II, as well as the
applicable statutory provisions regarding surge protection.
Installation and maintenance may only be performed by a
qualified electrician.
ETV100_090621 / 006-1340
Technical specifications are subject to change.
© WE-EF 2022
WE-EF LIGHTING
Installation and
Maintenance Instructions for
Inground Uplights,linear
ETV100 Series
with installation blockout
BEV
Advertisement
Related Manuals for WE-EF ETV100 Series
Summary of Contents for WE-EF ETV100 Series
- Page 1 Please note the mains. In that case, the LED on the surge protector no ETV100 Series various protection levels for Class I and II, as well as the longer lights up.
- Page 2 ETV149 ......64 LED 4-6W* * Nominal power, for latest data refer to www.we-ef.com Installation Accessories ø...
- Page 3 Installation Installation blockout BEV The product must be installed and maintained by Warning: Switch off mains electrical supply prior to Ensure that proper drainage is provided, e.g. a gravel a suitably qualified professional in compliance with installing and connecting the luminaire. Do not open bedding.
- Page 4 Installation luminaire uplight ETV Linear inground luminaire ETV100 pic. 2 1) Switch off mains electrical supply. 2) The luminaire is pre-wired and the lamp/LED inclu- 6) Install the spacer E. In case the space for the lumin- ded. An opening of the luminaire is not necessary. aire(s) is not sufficient you can remove individual silicone buffer G.
