Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Inground Luminaire
ETV100 LED
Advertisement
Related Manuals for WE-EF ETV100 Series
Summary of Contents for WE-EF ETV100 Series
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Inground Luminaire ETV100 LED Do not open during installation Surge Protection This product is factory-sealed. This product features built-in surge protection circuitry in compliance with Refer to the instructions contained in this applicable standards.
- Page 2 Inground Luminaire ETV100 Product Dimensions: ETV100 series ETV120 ETV130/ETV130-CC ETV140/ETV140-CC 1227 IP67, IK08. Class I. ta = 25°C Mounting Accessories: Installation blockout Type I Type II B = 160 mm B = 130 mm for 1 x ETV120 186-0306 186-0281...
-
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out Warning: Do not open luminaire while mains supply is switched on. -
Page 4: Installation
Installation The product must be installed and maintained by a building/construction and/or electrical regulations and relevant legislation. Warning: Switch off mains electrical supply prior to installing and connecting the luminaire. Notice: than the original manufacturer, then the warranty will no longer be valid and shall become the full respon- sibility of the modifying person/organisation. - Page 5 Blockout Installation Procedure (during earth or masonry work) 1) Remove installation cover A out of installation 2) Ensure that proper drainage is provided. blockout B. Holes J are for drainage. 3) Feed mains supply cable C (and second 4) Place mains cable C (and second cable E for cable E for through wiring) through holes through wiring) at bottom area of blockout, inside blockout.
- Page 6 Luminaire Installation Procedure 1) Switch off mains electrical supply. 2) Check that rating shown on luminaire label conforms with mains electrical supply. 02/19 IP67 ETV120 220-240V/50-60 Hz 186-XXXX SOE XXXXXXX (example) 3) Luminaire is pre-wired and LED included. 4) Remove installation cover A from blockout B. Opening the luminaire is not necessary.
- Page 7 5) Take sealable junction box G from its bag and open it. Warning: Be careful to not get dirt inside the gel connector when opened and connecting mains cable. Connect leads of luminaire cable D and mains supply cable C (and second cable E for through wiring) to respective terminals in terminal connector F.
- Page 8 6) Place sealable junction box G and luminaire H inside blockout. Make sure no cable is squeezed. 7) Install spacers I. To remove luminaire unfasten screws K out of spacers I until you can grab their heads. Insert lever L between head of screws and spacers. Lift spacers in an upwards direction.
- Page 9 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com WE-EF LIGHTING United Kingdom Tel +44 844 880 5346 Fax +44 844 880 5347 info.uk@we-ef.com TO9258W0719 © WE-EF 2019 subject to change.
- Page 10 WE-EF LEUCHTEN Installation and Maintenance Instructions Wiring instruction for hybrid DMX cable...
- Page 11 Installation The product must be installed and maintained by a suitably uali ed professional in compliance ith latest building/construction and/or electrical regulations and relevant legislation. The installation on site must comply ith local and/or national health and safety regulations.
-
Page 12: Installation Procedure
Installation Procedure 1) Scope of supply. DMX IN + White, Shield, – Red Hybrid cable DMX OUT + White, Shield, – Green Power L - Brown, N - Blue, Earth - Green/Yellow 1.5 mm 0.14 mm 2) Prepare cable for supply and DMX cabling. 3) Feed DMX cables B and C through mains supply terminal block A for po er supply and connect luminaire supply D to terminal block A. - Page 13 4) Connect leads of mains supply cables: 5) Place terminal block A inside sealable – D to luminaire junction box J, ensure cables do not cross – B incoming and that cable sheaths must be contained – C optional outgoing mains supply for ithin gel.
- Page 14 8) Tie case by cable ties F. 9) Connect leads of external DMX cables (DMX in/out) from luminaire to terminal block A1 of second sealable junction box: – D1 to luminaire – B1 DMX out – C1 DMX in DMX out + DMX in + DMX in –...
- Page 15 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.s it erland e-ef.com info.usa e-ef.com WE-EF LIGHTING United Kingdom Tel +44 844 880 5346 Fax +44 844 880 5347 info.uk e-ef.com TO9256W0419 © WE-EF 2019 Technical speci cations are subject to change.
