This product is factory-sealed.
Do not open during installation
Refer to the instructions contained in this
document for details.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Inground Luminaire
ETC339-FS LED
EVC339-FS LED
INSTALLER
HOTLINE
+61 458 933 399
7am – 7pm AEST
Advertisement
Related Manuals for WE-EF ETC339-FS LED
Summary of Contents for WE-EF ETC339-FS LED
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Inground Luminaire ETC339-FS LED EVC339-FS LED INSTALLER HOTLINE +61 458 933 399 7am – 7pm AEST This product is factory-sealed. Do not open during installation Refer to the instructions contained in this document for details.
- Page 3 Marker Light ETC339-FS EVC339-FS ø 272 IP67, Class I, ta = 25°C...
- Page 4 Light Source Maintenance Apart from cleaning the outside of the luminaire, no special maintenance is necessary. Luminaire should be discarded in case the supply cable is damaged.
- Page 5 Installation Methods Installation The product must be installed and maintained by a Important: The luminaire is factory-sealed and does suitably quali ed person in compliance with the latest not need to be opened during installation. applicable regulations and relevant legislation. Ensure that proper drainage is provided for the shown Ensure the luminaire and lens is clear of dirt and debris.
- Page 6 Phase One Phase Two Blockout Installation Procedure Luminaire Installation and Electrical Connection (during earth or masonry work) 5) Switch off mains electrical supply. 1) A suitable recess to be provided to accommodate 6) Check that rating shown on luminaire label con- installation blockout/mounting ring assembly B/M.
- Page 7 Fig. III...
- Page 8 WE-EF LIGHTING United Kingdom INSTALLER HOTLINE Tel +44 844 880 5346 Fax +44 844 880 5347 +61 458 933 399 info.uk@we-ef.com 7am – 7pm AEST TO913 W0 1 © WE-EF 201 Technical speci cations are subject to change.
- Page 9 WE-EF LIGHTING Installation and Maintenance Instructions WE-EF LIGHTING Installation WE-EF LIGHTING Installation GEL JUNCTION BOX, c/w 6 mm T/B and Maintenance Instructions and Maintenance Instructions 185-1624 ON/OFF & DALI/1-10V ON/OFF & DALI/1-10V These instructions cover wiring of luminaires for different lighting control systems:...
-
Page 10: Installation
Installation This instruction sheet is specific to underground standard cable connections for inground up- lights supplied by WE-EF complete with pre-installation blockout. This product is designed for single use only. It is also specific to a maximum of two x 5 core (1.5 mm2 to 4 mm2) circular or flat TPS. - Page 11 sheet, please refer to your supplier for approved instruction information. Installation Procedure - ON/OFF, 1-10V or DALI luminaires GEL JUNCTION BOX, c/w 6mm T/B 185-1624 Prepare cables a) ON/OFF 25 - 40mm 25 - 40mm 15mm 25 - 40mm 25 - 40mm b) DALI/1-10V* 15mm *Confirm suitability of 1-10V connections as shown...
- Page 12 2) Secure wires within terminal block with hex key supplied a) ON/OFF b) DALI/1-10V* T T i i g g h h t t e e n n t t o o 3 3 N N *Confirm suitability of 1-10V connections as shown 3) Placement inside junction box Cutout sides where required...
- Page 13 4) Click closed the junction box Click! Click! Click! Click! * Separate A – Do not lay cables on top of each other 5) Ensure gel dispersion ** B – Be sure to have gel dispersion between cables...
- Page 14 6) Cable ties are for locking case at end 7) Power up...
- Page 15 Installation Procedure - DMX luminaires (illustrations are exemplary) 1) Scope of supply. B: DMX data cable C: Junction box for DMX data cables Luminaire (with 120 Ohm resistor) Luminaire 185-1624 0.6/1kV 185-1624 0.6/1kV...
- Page 16 A and main supply cable O (and second cable F for through D: L = Phase, N = Neutral, = Earthing. Attention: Click closed the junction box, ensure cables do not lay on top of each other Click! Click! Click! Click!
- Page 17 5 Ensure gel dispersion, and that individual insulation of cable cores is totally enclosed in the gel. 6 Tie the ends of the case closed with cable ties K K...
- Page 18 7) Connect luminaire’s DMX data cables B and external DMX cables E box C: White = DMX+, Red = DMX– Attention: 8) A t the end of each DMX bus: DMX must be terminated by connecting 120 ohm resistor G (placed on...
- Page 19 10) T est electrical system before burying cables.
- Page 20 Drainage 1) Ensure that proper drainage is provided for 2) Ensure a suitable recess. the shown installation methods: a) In landscape/paved areas, sand or concrete with gravel base (Fig. I). b) With fully concreted installation, drainage piping must be provided (Fig. II). Fig.
- Page 21 United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 INSTALLER HOTLINE +61 458 933 399 7am – 7pm AEST TO9259W042020_ Rev2_130521 © WE-EF 2021...
