ENGLISH (Original instructions)
1. Recessed part in the battery
cartridge cover
2. Battery cartridge cover
3. Red part

SPECIFICATIONS

Model
Vibrations per minute (min
Vibration amplitude
Vibration head (diameter x length)
Flexible shaft assembly length
Overall length
Net weight
Rated voltage
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Specifications and battery cartridge may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
................. Read instruction manual.
................ Do not use the tool in the rain.
................ Do not clean the tool with water.
Intended use
The tool is intended for removing bubbles from concrete
when casting concrete.
General Power Tool Safety
Warnings
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and
instructions for future reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
Explanation of general view
4. Button
5. Battery cartridge
6. Cover
7. Indicator lamps
DVR340
-1
) 12,500
800 mm
1,083 mm
3.1 kg
D.C. 14.4 V
END003-5
ENE055-1
GEA006-2
8.
9.
10. Slope
DVR440 DVR350
12,500 13,000
1.0 mm
25 mm x 221 mm
1,200 mm 800 mm
1,483 mm 1,083 mm
3.6 kg 3.0 kg
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
Electrical safety
4. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
5. Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
6. Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
7. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
8. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
9. If operating a power tool in a damp location is
unavoidable, use a ground fault circuit interrupter
(GFCI) protected supply. Use of an GFCI reduces
the risk of electric shock.
Personal safety
10. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
Check button
Switch lever
DVR450
13,000
1,200 mm 2,400 mm
1,483 mm 2,683 mm
3.5 kg
D.C. 18 V
DVR850
12,500
5.2 kg
3
