Name Of Parts And Functions - Haier AU84NBTBAA User Manual

Outdoor unit network two by one type room air conditioner
Hide thumbs

Advertisement

Name of Parts and Functions

Note:
Do not block the air inlet and air outlet, otherwise the performance of the air
conditioner may be lowered and it will make the protection device act.
Air outlet
In COOLING operation, it
blows out hot air.
In HEATING operation, it
blows out cold air.
Fixing screw bolt
The interface of the refrigerant pipe
(two sides)
The wire hole for power cable
Air inlet
Right and left two sides and rear,
totally 3 sides
