DUCT TYPE AIR CONDITIONER
INSTRUCTION
MANUAL
AD88NAHBEA
AU88NATBEA
No. 0010574404

Advertisement

loading

  Also See for Haier AD88NAHBEA

  Related Manuals for Haier AD88NAHBEA

  Summary of Contents for Haier AD88NAHBEA

  • Page 1 DUCT TYPE AIR CONDITIONER INSTRUCTION MANUAL AD88NAHBEA AU88NATBEA No. 0010574404...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS CAUTIONS SAFETY PRECAUTIONS PARTS AND FUNCTIONS MALFUNCTION CARE AND MAINTENANCE FOR PREPARATION OF HEATING IS THE UNIT INSTALLED CORRECTLY INSTALLATION MANUAL FOR INDOOR UNIT INSTALLATION MANUAL FOR OUTDOOR UNIT 7-10 13-21 22-28...
  • Page 3: Cautions

    Damaged air conditioners are not to be put into operation. In case of doubt, consult your supplier. Use of the air conditioner is to be carried out in strict compliance with the relative instructions set forth in the User's Guide.
  • Page 4 Unless the circuit breaker is installed, it could cause elecrical shocks. Install on the place where can endure the weight of air conditioner. Bodily injury could result by a careless installation. WARNING Do not poke the air inlet or outlet with a bar, etc.
  • Page 5: Safety Precautions

    If the structure is not repaired immediately, the unit could topple down to cause apersonal injury. WARNING When the air conditioner is relocated, contact your dealer or a pro- fessional installer. Improper practice of installation could cause water leakage, electric shock or fire.
  • Page 6 6. The breaker of the air conditioner should be all-pole switch; and the distance between its two contacts should be no less 3mm.
  • Page 7: Parts And Functions

    PARTS AND FUNCTIONS Indoor Unit Air outlet Duct Duct Drainpipe Air inlet Air outlet Air inlet Air inlet...
  • Page 8: Malfunction

    Isn't it warming up? page 9 When the air conditioner does not operate properly after you have checked the above mentioned items or when the following phenomenon is observed, stop the operation of the air conditioner and contact your sales dealer.
  • Page 9 Water or steam generates from the outdoor unit during heating. When the air conditioner is started, when the compressor starts or stops during operation or when the air conditioner is stopped, it sometimes sounds "shuru shuru" or "gobo gobo". It is the flowing sound of the refrigerant, and it is not a trouble.
  • Page 10: Care And Maintenance

    Operate the unit with FAN mode on a fair day for about half a day to dry the inside of the unit well. Stop operation and turn off the power supply switch. Electric power is consumed even the air conditioner is in stop.
  • Page 11: For Preparation Of Heating

    Defrosting operation When a room is warmed with a heat pump type air conditioner, frost accumulates on the heat ex- changer of outdoor unit along with the drop of indoor temperature. Since the accumulated frost re- duces the effect of warming, it is necessery to automatically switch the operation to the defrosting mode.
  • Page 12: Is The Unit Installed Correctly

    Besides, construction expense is charged for removal or reinstallation. The capacity of air conditioner will decrease by contamination of inside of unit when it is used for about three years although depending upon the circumstances under which it is used, and so in addition to the usual maintenance service, special inspection/maintenance service is necessary.
  • Page 13: Installation Manual For Indoor Unit

    Take care that wiring does not rise upward, and accurately install the lid/service panel. Its improper installation can also result in heat generation or fire. When setting up or moving the location of the air conditioner, do not mix air etc. or anything other than the designated refrigerant (R22) within the refrigeration cycle.
  • Page 14: Installation Manual For Indoor Unit

    INSTALLATION MANUAL FOR INDOOR UNIT All Wiring of this installation must comply with NATIONAL, STATE AND LOCAL REGULATIONS. These instructions do not cover all variations for every kind of installation circumstance. Should further information be desired or should particular problems occur, the matter should be referred to your local distributor. BE SURE TO READ THESE INSTRUCTIONS CAREFULLY BEFORE BEGINNING INSTALLATION.
  • Page 15 INSTALLATION MANUAL FOR INDOOR UNIT 3. Preparation before installation (1) The position relation among hoisting screw (unit: mm) Down side Up side (2) If necessary, cut the opening installation and checking needed on the ceiling. (If has ceiling) Before installation, finish the preparation work of all the pipes (refrigerant, drainage) and wire (wire controller connection wire, indoor and outdoor unit connection wire) of indoor unit, so that after installation, they can be immediately connected with outdoor unit.
  • Page 16 INSTALLATION MANUAL FOR INDOOR UNIT Adjusting to the levelness (a) Adjust the out-of levelness using a level or by the following method. Make adjustment so that the relation between the lower surface of the unit proper and water level in the hose becomes as given below.
  • Page 17 Insulation Air outlet Please consult the after-sales service worker of Haier Air Conditioner for the choosing and installation of suction inlet, suction duct, discharging outlet and discharging duct. Calculating the design drawing and outer static pressure, and choose the discharging duct with proper length and shape.
  • Page 18 /h(m 600(10) 1,000 1,200(20) 1,400 1,600 Bad example Good example Air volume Air conditioner 2400m (40m 600m (10m Equipped with air filter (bought) Calculate as per 1m length 1Pa, 1Pa/m Each bend takes as a3~4m long straight duct Calculate as 25Pa...
  • Page 19 INSTALLATION MANUAL FOR INDOOR UNIT 8. The attentive matters in installation of air suction and discharging duct Recommend to use anti-frost and sound-absorbing duct. (locally bought) The duct installation work should be finished before the fitment of ceiling. The duct must be heat insulated. The specific air-discharging outlet should be installed at the place where the airflow can be reasonably distributed.
  • Page 20 INSTALLATION MANUAL FOR INDOOR UNIT 10. The operation method of fan controller Through the fan controller switch in the electric box, the air volume of this unit can be continuously adjusted. It is unnecessary to adjust air volume through the duct side wind level (unit outside static adjustment). The air volume set should be in the operation air volume range.
  • Page 21: Refrigerant Pipe

    INSTALLATION MANUAL FOR INDOOR UNIT 11. Refrigerant pipe [The air side pipe, liquid side pipe must be faithfully heat insulated, if no heat insulation, it may cause water leakage.] The outdoor unit has been charged with refrigerant. When connect the pipe to the unit or dismantling the pipe from the unit, please follow the figure shown, use spanner and torque spanner together.
  • Page 22: Installation Manual For Indoor Unit

    INSTALLATION MANUAL FOR INDOOR UNIT Electric wiring DANGER OF BODILY INJURY OR DEATH TURN OFF ELECTRIC POWER AT CIRCUIT BREAKER OR POWER SOURCE BEFORE MAKING ANY ELECTRIC CONNECTIONS. GROUND CONNECTIONS MUST BE COMPLETED BEFORE MAKING LINE VOLTAGE CONNECTIONS. (1) Selection of size of power supply and interconnecting wires. Precautions for Electric wiring Electric wiring work should be conducted only by authorized personnel.
  • Page 23: Installation Manual For Outdoor Unit

    INSTALLATION MANUAL FOR OUTDOOR UNIT Selection of installation site It should be installed at places where it is firm enough to withstand the weight of the air conditioner to prevent falling. Typhoon and earthquake prevention. It should be installed according to specific requirements.
  • Page 24 INSTALLATION MANUAL FOR OUTDOOR UNIT Refer to the following figure for the distance between the foundation bolts. (2)When the refrigerant pipe is connected from the bottom of the unit,the unit should be raised at least 500mm(see the figure below) (3)In snowy regions,snow-proof facilities should be used(see the figure below).
  • Page 25 INSTALLATION MANUAL FOR OUTDOOR UNIT Base plate (6) During welding,the gas pipe valve must be cooled down with a wet cotton cloth. (7)The maximum connnection pipe is 50 meters ,the maximum drop difference between indoor unit and outdoor unit is 30 meters. (8)It should installation the liquid check-ring and accumulator according to the outdoor unit and indoor unit position.(see the attached diagram) Diag1.outdoor unit below the indoor unit.
  • Page 26 INSTALLATION MANUAL FOR OUTDOOR UNIT Outdoor unit pipelines connection According to the pipeline connection method connection the distribute pipes and inlet & outlet liquid pipes. Leak Test Leak test must be made after connection of the refrigerant pipe according to the following diagram. Close all the gas and liquid valves.To prevent nitrogen gas from invading the outdoor circulating system,close the valve tightly before pressure increase,(Both the gas and liquid valves must be tightly closed.)
  • Page 27 INSTALLATION MANUAL FOR OUTDOOR UNIT Step 1:Charge for more than 3 minutes under 0.3MPa(3.0kg/cm Step 2:Charge for more than 3 minutes under 1.5MPa(15kg/cm -----------Serious leakage may be found. Step 3:Charge for more than 24 hours under 3.0MPa(3.0kg/cm ----------Small leakage may be found. Check for pressure decrease Without pressure decrease-Pass With pressure decrease-Check for leaage.
  • Page 28 INSTALLATION MANUAL FOR OUTDOOR UNIT Use a vacuum pump with high degree of vacuum(below-755mmHg) and large volume displacement (above 40L/min) The pumping time depends on the length of the connecting pipe.Generally,it takes about 2-3 hours.Make sure that the Y-shaped valves on both the gas and liquid sides are closed before pumping.
