- Page 5 1. Prepare 6 bolt assemblies by first inserting a lock washer (#F) onto the bolt (#C) then a flat washer (#E) onto that same bolt (#C). 2. Align the legs (#2) to the holes along the back of the headboard (#1), then insert 3 bolt assemblies into each leg and secure.
- Page 6 Align the drawer slat support (#6) to the hole along the bottom of the drawer slat (#5), then insert the threaded end of the support stopper (#13) into that same hole from above. Turn right to tighten and make sure both supports are firmly secured. Adjust according to the ground level.
- Page 7 Align the end of the runners to the slat (#5), then insert a screw (#A) into each end. Secure using a screwdriver. Place the slats (#7) onto the rails, then align the center slat (#10) to the holes along the bottom of those slats (#7) and the slat supports (#9).
- Page 8 Place the bed slats (#8) onto the rails, then insert a screw (#B) into each end. Secure using a screwdriver. Place the slat cover (#12), then insert the screws (#A) and secure using a screwdriver.
- Page 13 1. Prepare 6 bolt assemblies by first inserting a lock washer (#G) onto the bolt (#C) then a flat washer (#F) onto that same bolt (#C). 2. Align the legs (#2) to the holes along the back of the headboard (#1), then insert 3 bolt assemblies into each leg and secure.
- Page 14 Align the drawer slat support (#6) to the hole along the bottom of the drawer slat (#5), then insert the threaded end of the support stopper (#14) into that same hole from above. Turn right to tighten and make sure both supports are firmly secured. Adjust according to the ground level.
- Page 15 Align the end of the runners to the slat (#5), then insert a screw (#A) into each end. Secure using a screwdriver. Place the slats (#7) onto the rails, then align the center slat (#10) to the holes along the bottom of those slats (#7) and the slat supports (#9).
- Page 16 Place the bed slats (#8) onto the rails, then insert a screw (#B) into each end. Secure using a screwdriver. Place the slat cover (#12), then insert the screws (#A) and secure using a screwdriver.
- Page 17 2. Align the side rail caps (#13) to the holes, then insert a bolt assembly into each hole. Secure using the Allen wrench. 1. Prepare 10 bolt assemblies by first inserting a lock washer (#G) onto the bolt (#D) then a flat washer (#F) onto that same bolt (#D).
- Page 22 1. Prepare 6 bolt assemblies by first inserting a lock washer (#F) onto the bolt (#C) then a flat washer (#E) onto that same bolt (#C). 2. Align the legs (#2) to the holes along the back of the headboard (#1), then insert 3 bolt assemblies into each leg and secure.
- Page 23 Align the drawer slat support (#6) to the hole along the bottom of the drawer slat (#5), then insert the threaded end of the support stopper (#13) into that same hole from above. Turn right to tighten and make sure both supports are firmly secured. Adjust according to the ground level.
- Page 24 Align the end of the runners to the slat (#5), then insert a screw (#A) into each end. Secure using a screwdriver. Place the slats (#7) onto the rails, then align the center slat (#10) to the holes along the bottom of those slats (#7) and the slat supports (#9).
- Page 25 Place the bed slats (#8) onto the rails, then insert a screw (#B) into each end. Secure using a screwdriver. Place the slat cover (#12), then insert the screws (#A) and secure using a screwdriver.
