Assembly Instructions
CM7008F/Q
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 7
Rev.14-08-04
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7008F
Summary of Contents for Furniture of America CM7008F
- Page 1 Assembly Instructions CM7008F/Q ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3 of 7...
- Page 4 Before you begin, please read Page 3 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 8 pcs Headboard Bolt 5/16”x1” #B x 6 pcs #2 x 2 pcs Bolt 5/16”x1-5/8”...
- Page 5 Due to the size and/or weight of this product, it is highly recommended that the assembly should be done near the area of its intended location. Make sure you have enough space to move around during the assembly. ALWAYS have at least two people to help with transporting and assembling the product to avoid any potential injury and/or damage.
- Page 6 Prepare 4 bolt assemblies by #A x 8 pcs inserting FIRST the lock #D x 8 pcs washer (#E) onto the bolt (#A) #E x 8 pcs and then the flat washer (#D) onto the SAME bolt (#A), in that order. Insert the bolt assemblies through the right and left side of the pre-drilled holes of the...
- Page 7 #B x 4 pcs Align the assembled #D x 4 pcs support rail (#4) with the #E x 4 pcs pre-drilled holes on the center of the headboard (#1) and the footboard (#3). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#E) onto the bolt (#B) and then the flat Turn right (clockwise) to tighten...
