Table of Contents

For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
DIFFICULT
CM7059
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
(Not Included)
Rev: 2017-05-08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CM7059 and is the answer not in the manual?

Questions and answers

Related Manuals for Furniture of America CM7059

Summary of Contents for Furniture of America CM7059

  • Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7059 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult).
  • Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 22pcs Screw ( 4 x 1-3/8") Headboard Panel Ø #2 x 1pc #B x 24pcs Screw ( 4 x 5/8"...
  • Page 4 Hook each end of the bed rails (#3) onto the slots along the headboard panel (#1). Place the support rails (#4) onto the slots along the bed rails (#3), then insert a screw (#A) into each hole. Secure using a screwdriver.
  • Page 5 #A x 2pcs #C x 6pcs #D x 12pcs Insert the threaded end of the support legs into the holes along the center rail (#6), then turn right to tighten. Adjust according to leveler the ground level. Page 5 of 7...
  • Page 6 Place the center rail (#6) onto the center slots along the headboard and foot- board. Insert a screw (#A) into each end and secure using a screwdriver. Place the slats (#7) onto the rails, then insert a screw (#A) into each hole. Secure using a screwdriver.
  • Page 7 Place the dust boards (#9) onto the bottom end of the slats, then insert a screw (#B) into each hole. Secure using a screwdriver.
