Assembly Instructions
CM7016 F / Q
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
Allen Wrench
shows the degree of effort needed in
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
Wrench
products, two persons are recommended.
(Not Included)
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 7
Rev.14-11-18
Advertisement
Related Manuals for Furniture of America CM7016 F
Summary of Contents for Furniture of America CM7016 F
- Page 1 Assembly Instructions CM7016 F / Q ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Wrench products, two persons are recommended.
- Page 2 Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List #2R x 1 pc #1 x 1 pc Right H/B Side Headboard #2L x 1 pc #3 x 2 pcs Left H/B Side Side Rail...
- Page 4 Due to the size and/or weight of this product, it is highly recommended that the assembly should be done near the area of its intended location. Make sure you have enough space to move around during the assembly. ALWAYS have at least two people to help with transporting and assembling the product to avoid any potential injury and/or damage.
- Page 5 #A x 8 pcs #D x 8 pcs #E x 8 pcs Align the right H/B side (#2R) with the pre-drilled holes on the right side of the headboard (#1). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#D) onto the bolt (#A) and then the flat washer (#E) onto the SAME bolt (#A), in that order.
- Page 6 Align the 2 support rail legs (#8) with the pre-drilled holes of the support rail (#5). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#D) onto the bolt (#B) and then the flat washer (#E) onto the SAME bolt (#B), in that order.
- Page 7 Align the assembled support rail (#5) with the pre-drilled holes on the center of the headboard (#1) and the footboard (#4). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#D) onto the bolt (#B) and then the flat washer (#E) onto the SAME bolt (#B), in that order.
- Page 8 Assembly Instructions CM7016CK-EK ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Wrench products, two persons are recommended.
- Page 9 Page 2 of 7...
- Page 10 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List #2R x 1 pc #1 x 1 pc Right H/B Side Headboard #2L x 1 pc #3 x 2 pcs Left H/B Side Side Rail...
- Page 11 Due to the size and/or weight of this product, it is highly recommended that the assembly should be done near the area of its intended location. Make sure you have enough space to move around during the assembly. ALWAYS have at least two people to help with transporting and assembling the product to avoid any potential injury and/or damage.
- Page 12 #A x 8 pcs #D x 8 pcs #E x 8 pcs Align the right H/B side (#2R) with the pre-drilled holes on the right side of the headboard (#1). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#D) onto the bolt (#A) and then the flat washer (#E) onto the SAME bolt (#A), in that order.
- Page 13 Align the 2 support rail legs (#8) with the pre-drilled holes of the support rail (#5). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#D) onto the bolt (#B) and then the flat washer (#E) onto the SAME bolt (#B), in that order.
- Page 14 Align the 2 assembled support rails (#5) with the pre-drilled holes on the headboard (#1) and the footboard (#3). Prepare 8 bolt assemblies by inserting FIRST the lock washer (#D) onto the bolt (#B) and then the flat washer (#E) onto the SAME bolt (#B), in that order.
- Page 15 Assembly Instructions CM7016T ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 16 Page 2 of 5...
- Page 17 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 8 pcs Headboard Bolt 5/16”x2” #B x 8 pcs #2R x 1 pc Bolt 5/16”x1-1/2”...
- Page 18 #A x 8 pcs #D x 8 pcs #E x 8 pcs Align the right H/B side (#2R) with the pre-drilled holes on the right side of the headboard (#1). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#D) onto the bolt (#A) and then the flat washer (#E) onto the SAME bolt (#A), in that order.
- Page 19 Prepare 4 bolt assemblies by #B x 8 pcs inserting FIRST the lock #D x 8 pcs washer (#D) onto the bolt (#B) #E x 8 pcs and then the flat washer (#E) onto the SAME bolt (#B), in that order. Insert the bolt assemblies through the pre-drilled holes of the right and the left side of...
