ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7047Q
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
(Included)
(Not Included)
Rev: 18-0 8 - 31
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7047Q
Summary of Contents for Furniture of America CM7047Q
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7047Q ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench (Included) shows the degree of effort needed in assembling a specific product (with 1 being Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1pc #A x 6pcs Headboard Bolt Ø5/16" x 1-3/8" #2 x 2pcs #B x14pcs Headboard Leg(L&R) Lock Washer Ø5/16"...
- Page 4 Exploded View Align HB legs (#2R/L) to the headboard (#1), then secure by using bolts (#A) with washers (#B,C). #A x 6pcs #B x 6pcs #C x 6pcs Page 4 of 7...
- Page 5 Attach support legs (#6) to the storage footboard (#4). Adjust leveler of the support legs (#6) according to ground level. Remove handles from the inside of drawers, then reattach handles to the outside of drawers. Page 5 of 7...
- Page 6 Attach thread rods (#E) to the headboard (#1) and footboard (#4), then align side rails (#3) to the thread rods (#E). Secure by using hex nut (#G) with washers (#B,C,F). #B x 8pcs #C x 8pcs #E x 8pcs #F x 8pcs #G x 8pcs Attach slat support legs (#7) to the slats (#5), then adjust the leveler on the support legs (#7) according to ground level.
- Page 7 Align slats (#5) to the side rails (#3), then secure by using screws (#I). #I x 10pcs Align dusty panel (#8) to the bed, then secure by using screws (#J). # J x 6pcs Page 7 of 7...
