WCDMA Occupied Bandwidth (OBW) Verification (Option 44)
The tests in this section can be used to verify the WCDMA occupied bandwidth in WCDMA/HSDPA Signal
Analyzer Mode.
WCDMA Occupied Bandwidth Setup
Required Equipment:
• Anritsu MG3700A Vector Signal Generator
• Frequency Reference Symmetricom Rubisource T&M
• Power Meter, Anritsu Model ML2438A
• Power Sensor, Anritsu Model MA2482D
• Power Splitter, Aeroflex⁄Weinschel Model 1870A
• Fixed Attenuator, Aeroflex/Weinschel Model 44-10 (2)
• Adapter, Anritsu Model 34NN50A (2)
• RF Coaxial Cable, Anritsu Model 15NN50-1.5B
• Spectrum Master Model MS2721B
MS2721B MM
3-9 WCDMA/HSDPA Signal Analyzer (Options 44, 45, and 65) Verification
PN: 10580-00177 Rev. D
