③
Video Output
④
Audio Input
⑤
Power Output
⑥
DIP Switch
Connects to HDAVR to output video signal.
Connects to sound-pick-up devices to receive audio signal.
Supplies DC12V 2W power.
Dial switches to change output mode. Switch up indicates "ON", switch down
indicates "OFF."
Table 2-1
Design 4
