- Page 1 HDAVS Camera User’s Manual Version 1.0.0...
-
Page 2: Table Of Contents
Table of Contents General Introduction ........................1 Overview ........................1 Features ......................... 1 Device Framework ........................2 Installation............................ 3 Menu ............................. 5 HAVR Settings ......................5 Menu Operation ......................5 Appendix Ⅰ Maintenance ........................7... - Page 3 Welcome Thank you for purchasing our HDAVS camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference! Important Safeguards and Warnings 1．Electrical safety ...
- Page 4 Please do not provide two or more power supply modes for the device, otherwise it may cause damage to the device. Statement Please refer to the actual product for more details; the manual is just for reference. The manual will be regularly upgraded according to the product update;...
-
Page 5: General Introduction
1 General Introduction 1.1 Overview This series HDAVS camera conforms to the HDAVS standard. It supports video signal high- speed long distance transmission without any delay. It can be controlled by the HAVR conforming to the HDAVS. 1.2 Features Adopt high performance CMOS image sensor, megapixel definition. -
Page 6: Device Framework
2 Device Framework See Figure 2-1 for the dimension. Figure 2-1 See Figure 2-2 for the cable ports. Figure 2-2... -
Page 7: Installation
3 Installation Dome camera mainly uses ceiling installation; installation surface includes ceiling and wall. Users can install the device with the installation position map and the screws in the accessories bag. Attention: Please install the device in time after it is taken apart, which is to avoid the camera module being exposed to damp environment for too long. - Page 8 expansion boles on the installation surface, then insert the self-tapping screws into the expansion bolts and secure them firmly, fix the dome on the installation surface. Step 4 Connect the video output port of the device cable to the back-end HAVR device and connect the power port to power.
-
Page 9: Menu
4 Menu 4.1 HAVR Settings This HDAVS camera series can adjust OSD menu via coaxial control. After connected the camera to the HDAVS series HAVR, from Main Menu->Setting->System->PTZ, you need to select the channel number for access and set control mode as HDAVS and the protocol as ICR-SDI. - Page 10 Figure 4-3 See Sheet 4-1 for the details of button functions. Button Function Open menu Select menu item 、 Select menu value 、 Adjust lens zoom and auto trigger focus Note: Adjust lens focus Some of the buttons can only be applied for the motorized Auto focus under current vari-focal camera.
-
Page 11: Appendix Ⅰ Maintenance
Appendix Ⅰ Maintenance Attention: Please maintain the device according to the following instructions in order to ensure the image effect and long-term stable operation of the device. Maintenance for lens and mirror surface The lens and mirror surface are covered with antireflection coating, so it may produce hazardous substance and lead to performance reduction or scratch, dimness etc when it is stained with dust, grease, fingerprint and so on, please refer to the following methods to deal with once dirt is found:... - Page 12 Note This manual is for reference only. Slight difference may be found in the user interface. All the designs and software here are subject to change without prior written notice. All trademarks and registered trademarks mentioned are the properties of their respective owners.
