AVS Mid-Sized PTZ
Network Camera
Quick Start Guide

Table Of Contents

Features and Specifications
A.
Overview
Camera Installation
A.
Installation Steps
OSD and PTZ Functions
FAQ and Lightning Protection
www.icrealtime.com
IMPORTANT SAFEGUARDS AND WARNINGS
Electrical Safety
All installation and operation here should conform to your local electrical safety codes. The
power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the
Limited power source is rated DC24V/2.5A ± 25%. We assume no liability or responsibility for
all the fires or electrical shock caused by improper handling or installation. We are not liable for
any problems caused by unauthorized modification or attempted repair.
Transportation Security
Care must be given to avoid heavy stress, violent vibration or water damage during
transportation, storage and installation.
Installation
Do not apply power to the camera before completing installation. Please install the proper
power cut-off device during the installation connection. Always follow the instruction guide the
manufacturer recommended.
Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers. We are
not liable for any problems caused by unauthorized modifications or attempted repair.
Environment
This series network camera should be installed in a cool, dry place away from direct sunlight,
2
inflammable, explosive substances and etc. Please keep it away from the electromagnetic
2
radiation object and environment. Please make sure the CCD (CMOS) component is out of the
radiation of the laser beam device. Otherwise it may result in CCD (CMOS) optical component
damage. Please keep the sound ventilation. Do not allow the water and other liquid falling into
3-4
the camera. Lightning-proof device is recommended to be adopted to better prevent lightning
5
damage. The grounding studs of the product are recommended to be grounded to further
enhance the reliability of the camera.
5
Daily Maintenance
Please shut down the device and then unplug the power cable before you begin daily
6
maintenance work. Do not touch the CCD (CMOS) optic component. You can use the blower to
6-7
clean the dust on the lens surface. Always use the dry soft cloth to clean the device. If there is
too much dust, please use the water to dilute the mild detergent first and then use it to clean
the device. Finally use the dry cloth to clean the device. Please put the dustproof cap to protect
8
the CCD (CMOS) component when you do not use the camera.
8-9
Accessories
Be sure to use all the accessories recommended by manufacturer. Before installation, please
open the package and check all the components are included. Contact your local retailer ASAP
if something is broken in your package.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVS Series and is the answer not in the manual?

Questions and answers

Summary of Contents for IC Realtime AVS Series

  • Page 1: Table Of Contents

    IMPORTANT SAFEGUARDS AND WARNINGS Electrical Safety All installation and operation here should conform to your local electrical safety codes. The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated DC24V/2.5A ± 25%. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation.
  • Page 2: Cable Interface

    1B. Cable Interface 1A. OVERVIEW See Figure 1-2. This series PTZ camera utilizes High Definition Advanced Video System (HDAVS) technology, an HD-over-coaxial cable video FC Connector standard that allows long-distance, HD transmission of video, DC Power input audio, and control functions. The camera supports CVBS with an 24VAC input: Red(+), Black(-), Yellow/Green (ground) additional output.
  • Page 3 2A. INSTALLATION STEPS Step 3 Thread the Mount adaptor to the gooseneck mount and tighten Step 1 Remove any packaging tape or material on the camera. See the set screw as shown in Figure 2-3. Figure 2-1. Figure 2-1 Figure 2-3 Step 2 Drill the appropriate mounting holes and cable exit.
  • Page 4 Step 5 Install the camera with mount using the mounting bolts. See Figure 2-5. Figure 2-5 Step 2 Connect PTZ interface cables to the wall cable. Make sure they are waterproofed properly. Figure 2-6. Figure 2-6 www.icrealtime.com...
  • Page 5: Dip Switch Diagram

    2B. Dip switch settings 3A. OSD Operation See Figure 2-7 for Cover location and dip switch settings. To open the On Screen Display (OSD) make sure you set the protocol under Main Menu-> Camera-> PTZ. Make sure the Channel the PTZ is on is set to AVS mode.
  • Page 6: Osd Menu Functions

    3C. Setting Video Output 3B. OSD Menu Functions Note: PTZ is set to to AVS/ CVI by default as it is compatible with IC See the table below for Menu Index. Realtime HDVRs. Step 1 Open the OSD. Select System Setting and click Enter. System Setting System Information;...
  • Page 7 3D. Function Settings (continued) Scan- This is the horizontal rotation of the PTZ with defined left and Pattern- This a recorded set of movements that the PTZ will follow. right limits. Auto Scan No : You can select different scan numbers to Pattern No : You can select different scan numbers to ●...
  • Page 8: Faq

    4A. FAQ 4B. LIGHTNING PROOFING AND SURGE PROTECTION This PTZ adopts TVS lighting protection technology. It can Check whether the power supply is ● No self-test and no effectively prevent damages from various pulse signals below properly connected. image after the Check whether the main power and 6000W, such as sudden lighting and surge.
  • Page 9 4B. LIGHTNING PROOF AND SURGE PROTECTION (Continued) Figure 5-1 Figure 5-2 www.icrealtime.com...
