2.2

Cable

For more information about cable ports, see Table 2-1; for the operation method of ⑥(DIP
switch), see Table 2-2.
No. Port Name
①
DC 12V
Power Input
②
DC 12V or AC
24V Power
Input
Function
Inputs DC 12V power. Please be sure to supply power as instructed in the
Manual.
Device abnormity or damage could occur if power is not supplied correctly.
Inputs DC 12V or AC 24V power. Please be sure to supply power as
instructed in the Manual.
Device abnormity or damage could occur if power is not supplied correctly.
Figure 2-4
Figure 2-5
Figure 2-6
Figure 2-7
Figure 2-8
Figure 2-9
