Thank you for buying our product
Step By Step Assembly Instructions
PRE-ASSEMBLY PREPARATION
1.Please check the pack contents before attempting this product.
A full checklist of components is given in this leaflet. If any component are missing, please contact
the retailer from whom you bought this product.
2.This product is heavy, it should be assembled as near as possible to the point of use.
TAKE CARE WITH LIFTING to avoid personal injury and (or) damage to the product.
3.This product takes approximately 10 minutes to assemble with 2 people.
4.The fitting pack contains small items which should be :
KEPT AWAY FROM YOUNG CHILDREN.
5.Read this leaflet in full before commencing assembly.
6. You will require a crosshead screwdriver and Allen key (provided) to assemble this product.
7. WE RECOMMEND that you lay a protective cloth on your carpet during assembly, to prevent marking.
Gavotte 2 Door Wardrobe KD
( GV06 )
Assembly Instruction
Page 1
Advertisement
Table of Contents
Related Manuals for Multay Gavotte GV06
Summary of Contents for Multay Gavotte GV06
- Page 1 Gavotte 2 Door Wardrobe KD ( GV06 ) Assembly Instruction Thank you for buying our product Step By Step Assembly Instructions PRE-ASSEMBLY PREPARATION 1.Please check the pack contents before attempting this product. A full checklist of components is given in this leaflet. If any component are missing, please contact the retailer from whom you bought this product.
- Page 2 Gavotte 2 Door Wardrobe KD ( GV06 ) Assembly Instruction (A) Body and Top Cornice (B) Base Cabinet Panel and Fitting Identification Item Description Body and Top Cornice Base Leg Cabinet Allen Bolt Hanging Rail Allen Key Page 2...
- Page 3 Gavotte 2 Door Wardrobe KD ( GV06 ) Assembly Instruction Step 1. (Body and Top cornice) & Base Leg Cabinet Assembly Body and Top Cornice Base Leg Cabinet Move down Body and top cornice until match hole on base leg cabinet and insert allen bolt in hole (turn clockwise) Body and Top Cornice Allen Key...
- Page 4 Gavotte 2 Door Wardrobe KD ( GV06 ) Assembly Instruction Step 2. Adjustable Door Vertical Adjustable Horizontal Adjustable Lateral Adjustable Page 4...
- Page 5 Gavotte 2 Door Wardrobe KD ( GV06 ) Assembly Instruction Step 3. - Locate the Hanging Rails ( D ) into the support (D) Hanging Rails Step 4. - Remove stopper screw from the extending hanging rail (see #1) - Insert extending hanging rail on to the hole of side panel (see #2) - Attach stopper to extending hanging rail using screw (see #3) Extending Hanging Rails Stopper...
