Universal Instrumentation Amplifier Evaluation Module:
This user's guide describes the characteristics, operation, and use of the INAEVM-ALT-SO8, a universal
evaluation module (EVM) that is compatible with a variety of instrumentation amplifiers (INAs), specifically
those with the resistor gain pins at pins 2 and 3. This EVM is compatible with the SOIC-8 (D) package,
and is designed to evaluate the performance of the devices in both single-supply and dual-supply
configurations. This document includes the schematic, printed circuit board (PCB) layout, and BOM.
Throughout this document the terms evaluation board, evaluation module, and EVM are synonymous with
the universal INAEVM-ALT-SO8.
SBOU226 – February 2020
Submit Documentation Feedback
Universal Instrumentation Amplifier Evaluation Module: Alternate Pinout
Copyright © 2020, Texas Instruments Incorporated
User's Guide
SBOU226 – February 2020
Alternate Pinout
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Texas Instruments INAEVM-ALT-SO8
Summary of Contents for Texas Instruments INAEVM-ALT-SO8
- Page 1 Universal Instrumentation Amplifier Evaluation Module: Alternate Pinout This user's guide describes the characteristics, operation, and use of the INAEVM-ALT-SO8, a universal evaluation module (EVM) that is compatible with a variety of instrumentation amplifiers (INAs), specifically those with the resistor gain pins at pins 2 and 3. This EVM is compatible with the SOIC-8 (D) package, and is designed to evaluate the performance of the devices in both single-supply and dual-supply configurations.
-
Page 2: Table Of Contents
Universal INAEVM-ALT-SO8 Schematic (2) ..................Universal INAEVM-ALT-SO8 PCB List of Tables ................. Universal INAEVM-ALT-SO8 Bill of Materials Trademarks All trademarks are the property of their respective owners. Universal Instrumentation Amplifier Evaluation Module: Alternate Pinout SBOU226 – February 2020 Submit Documentation Feedback... -
Page 3: Overview
Reference voltage source flexibility • Convenient input and output filtering INA Pinout The INAEVM-ALT-SO8 is evaluates INAs that have the pinout shown in Figure 1, specifically those with the gain resistor pins at positions 2 and 3. Figure 1. Universal INAEVM-ALT-SO8 Pinout SBOU226 –... -
Page 4: Quick Start
NOTE: C9 and C15 are prepopulated with 0.1-µF power-supply decoupling capacitors. See the respective device data sheet for additional power-supply decoupling information. Universal Instrumentation Amplifier Evaluation Module: Alternate Pinout SBOU226 – February 2020 Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated... -
Page 5: Single-Supply Configuration
NOTE: C9 and C15 are prepopulated with 0.1-µF power-supply decoupling capacitors. It is not required to remove C15 for proper single-supply operation. See the respective device data sheet for additional power-supply decoupling information. SBOU226 – February 2020 Universal Instrumentation Amplifier Evaluation Module: Alternate Pinout Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated... -
Page 6: Single-Supply Configuration, Buffered Reference Connection
EVM for single-supply operation with a buffered-reference voltage connection. Figure 4. Single-Supply Configuration, Buffered Reference Connection Universal Instrumentation Amplifier Evaluation Module: Alternate Pinout SBOU226 – February 2020 Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated... - Page 7 NOTE: C9 and C15 are prepopulated with 0.1-µF power-supply decoupling capacitors. It is not required to remove C15 for proper single-supply operation. See the respective device data sheet for additional power-supply decoupling information. SBOU226 – February 2020 Universal Instrumentation Amplifier Evaluation Module: Alternate Pinout Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated...
-
Page 8: Evm Components
C1, C2, C5, and C6 are the populated bypass capacitors for the device, U1. Similarly, C3, C4, C7 and C8 are populated to provide supply bypassing for U2. Universal Instrumentation Amplifier Evaluation Module: Alternate Pinout SBOU226 – February 2020 Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated... -
Page 9: Schematic, Pcb Layout, And Bill Of Materials
Schematic The schematic for the PCB for the SOIC-8 EVM is shown in Figure 5 Figure Figure 5. Universal INAEVM-ALT-SO8 Schematic (1) SBOU226 – February 2020 Universal Instrumentation Amplifier Evaluation Module: Alternate Pinout Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated... -
Page 10: Universal Inaevm-Alt-So8 Schematic (2)
Schematic, PCB Layout, and Bill of Materials www.ti.com Figure 6. Universal INAEVM-ALT-SO8 Schematic (2) Universal Instrumentation Amplifier Evaluation Module: Alternate Pinout SBOU226 – February 2020 Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated... -
Page 11: Pcb Layout
Figure 7 is intended to show how the board is laid out; it is not intended to be used for manufacturing PCBs. Figure 7. Universal INAEVM-ALT-SO8 PCB SBOU226 – February 2020 Universal Instrumentation Amplifier Evaluation Module: Alternate Pinout Submit Documentation Feedback... -
Page 12: Bill Of Materials
Schematic, PCB Layout, and Bill of Materials www.ti.com Bill of Materials Table 1 provides the parts list for the EVM. Table 1. Universal INAEVM-ALT-SO8 Bill of Materials Designator Value Description Package Reference Part Number Manufacturer C1, C3, C5, C7 10 µF... - Page 13 STANDARD TERMS FOR EVALUATION MODULES Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms set forth herein.
- Page 14 www.ti.com Regulatory Notices: 3.1 United States 3.1.1 Notice applicable to EVMs not FCC-Approved: FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software associated with the kit to determine whether to incorporate such items in a finished product and software developers to write software applications for use with the end product.
- Page 15 www.ti.com Concernant les EVMs avec antennes détachables Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à...
- Page 16 www.ti.com EVM Use Restrictions and Warnings: 4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS. 4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling or using the EVM, including without limitation any warning or restriction notices.
- Page 17 Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief in any United States or foreign court. Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2019, Texas Instruments Incorporated...
- Page 18 TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable warranties or warranty disclaimers for TI products. Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2020, Texas Instruments Incorporated...
