- Page 1 2 Wire Digital Video System Installation Manual...
-
Page 2: Cable Distances
Introduction The Atigo door entry system is a simple 2 wire solution that can be expanded up to 4 entrance panels and 32 internal monitors. Programming of the camera module is done via built in DIP switches and touch keys. -
Page 3: Specifications
Video camera module A3101 A3101 Terminals 1. SET DIP switches for system configuration. 2. JP-LK Jumper for setting state of the NO contact 3. CN/KMB Digital display module connection port 4. CN/T-COIL Not in use 5. BUS L1, L2 bus line connecting to terminal... - Page 4 DIP switch settings for A3101 Video module functions and programming The system can be expanded up to 4 entrance panels and 32 internal monitors The video module is configured by 6 DIP switches. The DIP switches can be modified either before or after installation.
-
Page 5: Sound Volume Setting
Electric lock mode setting Sound setting When the Camera Module is in Programming When the Camera Module is in programming mode: mode: Press Key A, the Unlock Indicator will Press and hold Key A for 3 seconds to turn on with the warning sound of a long enter the Sound Option Mode, the Status Beep followed by a short Beep indicator will turn on and the current... - Page 6 Electric lock (internal power) Electric lock output is limited to 12Vdc, and a Electric lock (external power) maximum current of 250mA. Open contact output is limited to 24Vdc, Jumper setting JP-LK: and a maximum current of 1000mA. The jumper must be taken off before Normally closed mode connecting.
-
Page 7: Programming Table
Programming Table Digital keypad module A3202 Digital keypad module is designed as a digital call module and as a stand-alone access control keypad for a secure PIN entry with up to 40 pin codes capacity. Use programming table for programming user pin codes and other functions and features. -
Page 8: Programming Tags
Delete specific user tags Digital display module A3203 In standby mode present MASTER CARD DELETE tag to card reader. Present user tag you wish to delete to card reader. Or use keypad to enter room number you wish to remove all user tags from and press # to confirm. -
Page 9: Backup And Restore
Backup and restore Restore to factory default Audio/Video module is design to store Caution! programmed information about user door When using this procedure all information will numbers, proximity tags and pin codes. be lost and modules restored to default All information stored by the module can be factory settings. - Page 10 System layout - Distributor mode...
- Page 12 System layout - Riser mode...
