INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
These instructions are supplementary to the
Installation and Operating Instructions supplied with
the fireplace and should be kept together. Refer
to the Installation and Operating Instructions for
proper gas supply, safety requirements and operat-
ing instructions.
Visit www.townandcountryfireplaces.net for the most recent version of this manual
200916-12
TCWS38
BLACK DIAMOND
BURNER KIT
INSTALLATION
INSTRUCTIONS
PART#TCWS38.NG03D2
For TCWS38 Series D
Fireplaces
TCWS_38NG03D2
5056.425233D
