ROOTECH ACCURA 3000 User Manual

High accuracy digital power meter
Hide thumbs Also See for ACCURA 3000:
Table of Contents

Advertisement

Quick Links

Download this manual
ymbols
Caution
Indicates the presence of dangerous voltage which can cause severe injury or death
to persons if proper precautions are not followed.
Caution
Alerts users of the presence of hazards which can cause injury to persons, property
damage or damage to the device if proper precautions are not followed.
Note
Indicates major instructions for the installation, operation, and maintenance of the
product.
Indicates alternative voltage or current.
Indicates direct voltage or current.
Installation Considerations
The installation, operation, and maintenance of the product should be performed only by qualified,
competent personnel that have received appropriate training for high voltage and current devices.
◼ During normal operation of the product, hazardous voltages are present on the terminals that
connect PT/CT, digital inputs, power, and external I/O circuits. The PT/CT secondary can produce
lethal voltage or current caused by the energy of the primary.
◼ Standard safety precautions should be followed during the installation and maintenance of the
product, including removing PT fuses and shorting CT secondaries.
◼ Install the product in enclosures or a similar cabinet to prevent access to the terminal strips of
the product after wiring.
\
