Installation - Groen TDB/6 Operators & Service Manual

WARNING
INSTALLATION OF THE KETTLE MUST BE
DONE BY A CERTIFIED ELECTRICIAN OR
AUTHORIZED REPRESENTATIVE QUALIFIED
TO WORK WITH ELECTRICITY. IMPROPER
INSTALLATION CAN RESULT IN INJURY TO
PERSONNEL AN/OR DAMAGE
TO EQUIPMENT.
CAUTION
BEFORE ANY ELECTRICAL CONVERSION,
VERIFY THAT THE BRANCH CIRCUIT
WIRING IS ADEQUATE TO HANDLE ANY
INCREASE AMPERAGE REQUIREMENTS.
REFER TO THE ELECTRICAL
SPECIFICATIONS LISTED BELOW.
The TDB/6 Kettle is provided with complete internal wiring and is ready for immediate
connection. A wiring diagram is provided in this manual and on the inside of the
control housing service panel.
The completed unit has been operated at the factory to test all controls and heater
elements.
1. Set the kettle in place and level it. The base should be securely fastened to a
table or work surface. Installation under a ventilation hood is recommended.
2. Once the unit is anchored to a mounting surface, apply a small bead of silicone
caulk around the perimeter of the kettle base and seal the joint.
3. Provide electrical power as specified on the electrical information plate
attached to the equipment. Observe local codes and/or The National Electrical
Code in accordance with ANSI/NFPA 70 - (current edition).
4. Bringing the electrical service through the entrance at the rear of the support
housing, making a watertight connection with the incoming lines. (A BX
connection is not recommended.)
5. Confirm that the jacket water level is at or just above mid point of sight glass.
If the level is low, follow the instructions under "Jacket Filling and Water
Treatment" in the "Maintenance" section of the manual.
6. Ensure that the open end of the elbow on the outlet of the pressure relief
valve is directed downward. If it is not, turn the elbow to the correct position.
7. Any mechanical or electrical change must be approved by the Unified Brands
Engineering Department.

Installation

OM-TDB/6 7
