EN 54-23 Visual Alarm Devices
Warning: The product only works with Teknim TFP-121x, Intelligent Addressable Fire
Alarm panels.
Supported Flash Modes
Installation and Connections
1. Remove the head of the sounder from the base.
2. Mount the base part on the wall, using 2 of the 4 markings marked on the base.
3. Connect the cable according to the following diagram.
4. Replace the flasher. Make sure that the line on the head meets the long line on the base.
5.
Turn the flasher clockwise to the base, making sure that the terminals are tight.
A – Weighted Sound Level (max.)
Test
1.
TFS-1182 siren tests can be done in the menu of TFP-12XX Addressable Fire Alarm panels.
2.
Check if flasher error occurs when panel is operated.
3.
If sounder and flasher error, make sure the connections are made correctly.
4.
If no sounder and flasher error, move the panel to the test position from the menus.
5.
Run the sounder and flasher test. Observe the sounder and flasher side / flash status during the test
period.
6.
If the devices continuous warning lights are flashing during the test, the test is completed.
Manufacture
Bilgi Elektronik San. ve Tic. A.Ş.
Dudullu Organize Sanayi Bölgesi 1. Cadde İsmet Tarman İş Merkezi
No:1 Kat:2 No:32 Ümraniye / İstanbul / Türkiye
Telephone: +90 216 455 88 46 Fax: +90 216 455 99 06
www.bilgielektronik.com.tr
sales@bilgielektronik.com.tr
destek@bilgielektronik.com.tr
* 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste
in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info.
