- Page 1 User’s Manual SPP-C200 MOBILE PRINTER Ver. 1.00 http://www.bixolon.com...
-
Page 2: Table Of Contents
SPP-C200 Table of Contents Copyright .......................... 3 WARNING & CAUTION ..................... 6 Manual Introduction ....................... 9 Product Introduction ...................... 10 1. Prepration ........................11 1-1 Components ........................11 1-2 Front Part Names ......................12 1-3 Rear Part Names ......................12 2. -
Page 3: Copyright
It is strictly prohibited to copy, store, and transmit the whole or any part of the manual and any property of the product without the prior written approval of BIXOLON Co., Ltd. The information contained herein is designed only for use with this BIXOLON product. - Page 4 SPP-C200 Compliance information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 5 SPP-C200 Cet appareil contient un ou plusieurs émetteurs exempts de licence qui sont conformes aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils exempts de licence. Son utilisation est sujette aux deux conditions suivantes : (1) Cet appareil ne doit pas produire d'interférences.
-
Page 6: Warning & Caution
Do not connect multiple products to one Use only authentic products from single power outlet. Do not connect the BIXOLON. The company will not provide product to a loose power outlet. post-sale support for damage or other Use only power outlets that meet the quality issues that any fake standard. - Page 7 If there is a problem with the enter the product. Do not place heavy product, please contact the place of objects, liquids, or metals on the purchase. In addition, Bixolon product. It may start a fire. website (http://www.bixolon.com) It may damage the product.
- Page 8 The battery should only be charged using the adapter of the battery. Do not let metal contact the (+) and or charger provided by Bixolon, and if charging fails (-) terminals of the battery. If the (+) and (-) after the specified charging time (6 hours), stop terminals of the battery are smeared with charging.
-
Page 9: Manual Introduction
SPP-C200 Manual Introduction The manual provides basic information on the printer and describes how to install, use, and inspect it. To ensure your safety and prevent damage to your property, make sure you read the manual thoroughly before using the machine. -
Page 10: Product Introduction
SPP-C200 Product Introduction The SPP-C200 is a 2-inch thermal mobile label printer. The printer is compact and light and equipped with Bluetooth connectivity. The main features of the printer are as follows 1. 2-inch Mobile Label Printer 2. Maximum 80 mm/s (3.15ips) printing speed. -
Page 11: Prepration
SPP-C200 1. Prepration 1-1 Components • If any items are missing, contact the place of purchase. • The image may differ from the actual product. ※ Basic items SPP-C200 Battery Pack USB Type-C Belt Clip (A to C) Interface Cable... -
Page 12: Front Part Names
SPP-C200 1-2 Front Part Names Media Cover Charge Indication LED Error LED Power Button Status LED Cover Open Button Paper Feed Button 1-3 Rear Part Names Ver. 1.00 - 12 -... -
Page 13: Installation & Connection
SPP-C200 2. Installation & Connection 2-1 Battery Installation 1) Insert battery into the printer as pictured. 2) Connect the hook of the battery cover to the bottom of the printer. 3) Press the battery cover into place until you hear a “click” sound. -
Page 14: Battery Charging
Red LED Blinking properly • Charge the battery only after disconnecting the power to your device. • Use only genuine products supplied by Bixolon. Otherwise, the product may malfunction or there is a risk of personal injury. Ver. 1.00 - 14 -... -
Page 15: Media Installation
SPP-C200 2-3 Media Installation 1) Press the Open button to open the Media cover. 2) Insert the Media as shown in the image. (Remove any remaining core of a fully used Media roll.) 3) Take care to align the Media correctly. -
Page 16: Bluetooth Connection
SPP-C200 2-4 Bluetooth Connection 1) The printer can be connected to devices equipped with Bluetooth communication capacity (PDAs, PCs, etc.). 2) Use the Bluetooth connection function supported by the device to connect to the printer. • Refer to the Bluetooth Connection Manual for detailed information on its connection. -
Page 17: Interface Cable Connection
3) Connect USB Type-C cable ③ to your device’s (PDA, PC, etc.) USB port. ③ Power/Cable Port A USB Type-C cable that supports USB 2.0 or a USB Type-C cable supplied (sold separately) by Bixolon can be used as an interface cable. Ver. 1.00 - 17 -... -
Page 18: Use
SPP-C200 3. Use 3-1 Using Belt Clip 1) Insert the belt clip screw into the belt Belt Clip clip hole. Coin 2) Use a coin to tighten the belt clip screw as shown in the image. 3) Insert the clip to the belt. -
Page 19: Using Control Button
SPP-C200 3-2 Using Control Button 3-5-1 Power Button This button is used to turn the printer on and off. 1) When the printer is off, press this button for approximately 2 seconds to turn on the power. 2) When the printer is on, press this button for approximately 2 seconds to turn off the power. -
Page 20: Error/Batt/Status Led
SPP-C200 3-5-3 ERROR/BATT/STATUS LED • ERROR LED 1) If the red LED is blinking, the media cover is open or missing, or the head is overheated. (Replace the roll of media or turn off the printer for at least 10 minutes.) 2) If the red LED continues to blink, it may indicate a more serious problem with the product. -
Page 21: Self-Test
SPP-C200 4. Self-Test Run the self-test to check the setting information when you are setting up the printer for the first time or if there is a problem. If no issue is found with the printer after running the self-test, examine the other devices or peripherals and software. -
Page 22: Self-Test Sample
SPP-C200 4-2 Self-Test Sample SPP-C200 SELF TEST INFORMATION Firmware Version : V01.00 STOBi 010122 Configuration Memory Switch: MSW[1] 3/4 ON MSW[5] 1/2/3/4 ON MSW[6] 2/4 ON Speed: 80mm/s Density: 100% Emulation: BXL/POS Tear Option: Tear off Printer Method: Direct Thermal... -
Page 23: Cleaning
SPP-C200 5. Cleaning Media Sensor (B) Printhead (A) 1) Turn off the printer and disconnect all cables from the product. 2) Open the media cover and remove any media inside. 3) Clean the printhead (A) using the cloth or cotton swab soaked in alcohol for medical. -
Page 24: Appendix
SPP-C200 6. Appendix 6-1 Printer Specifications Item Description Printing Direct Thermal Printing Method Print Speed Up to 80 mm/s (3.15 ips) Resolution 203 dpi Font A: 12 × 24 Font B: 9 × 17 Font C: 9 x 24 Character Size... - Page 25 SPP-C200 Revision History Rev. Date Description 1.00 2022-04-28 Ver. 1.00 - 25 -...
